Swift Group Select 122 Owner's Handbook Manual page 73

Heating timer screen
On the heating screen press the more button
(right arrow) to set or view the daily heating
timers.
Timer
Press on the hour or minute value to change
the setting. Timers should be set in order
during the day (Timer 1 the earliest and
Timer 4 the latest) and use the 24 hour
clock.
Temperature
Press the temperature values to change
the setting. Each press will increment the
value from Off, then 5 degrees through to 30
degrees Celsius.
Water
Press the water values to change the
setting. Each press will step through the
available setting, which vary by appliance
type.
For Truma CP+ available settings are Off,
Eco or Hot.
For Alde 3020 available settings are Off,
Normal or Boost.
For Whale available settings are Off or On.
Note: To use these timer settings the
Heating mode must be set to Timer so
that the system can control the heating
appliance.
2.16 Air-conditioning
If your vehicle has been fitted with a
compatible air-conditioning unit then the
settings can be set / controlled by the EC800
control panel, the air-conditioner infrared
remote control or the Swift Command app.
The unit must be turned on with its power
switch before it can be controlled.
The related control panel screens are shown
below. For information in using the air-
conditioning from the Swift Command app,
please see the Swift Command User Guide.
Air-conditioning screen
Here you can select the operating mode, set the
target temperature and adjust the fan speed.
Lights
Press the lights button to control the LED
light built into the air-conditioning unit. Select
on or off to turn the light on or off, or select
dimmed to allow the light to be controlled
with other dimmable lighting in the vehicle.
Mode
Press mode button to select the required
operating mode. Select off to turn the air-
conditioner off. Note that available modes vary
according to the model of air-conditioner fitted.
Temperature
Use the temperature setting (+) or (-) buttons
to increase or decrease the temperature
setting. Available settings range from 5
degrees to 30 degrees Celsius.
Fan Speed
Use the fan speed setting (+) or (-) buttons
to increase or decrease the fan setting.
Note that available settings vary according
to the model of air-conditioner fitted.
71 71
