2.19 System Warnings
The system incorporates a number of warnings that are active at specific times. These are
summarised below, and also covered by relevant sections of this manual.
When a warning is active a warning box will appear on the control panel screen containing a
description of the warning along with an audible beeping sound.
Warning When
Fresh water With pump turned on and
level low fresh water level low (less than
25% full) Only available when
an on-board tank is fitted.
Waste water With pump turned on and
level full waste water level full. Only
available when an on-board
tank is fitted
With control panel power on
and leisure battery selected
(as active battery) and the
voltage level falls below 10V
With control panel power on
and leisure battery selected
(as active battery) and the
Leisure battery
voltage level is below 9V
voltage low
Note: This is an emergency cut off level to protect the battery from severe
damage. You should not rely on this cut off level during normal operation, but
manage your power consumption to a discharge level of 11.5V or above.
This cut off only applies to power drawn from the battery by the leisure
equipment that is controlled by the control panel power switch; it will not
protect the battery from discharge by permanently connected equipment.
Leisure battery With control panel power on
voltage high or off and leisure battery is
selected (as active battery)
and the voltage level rises
above 15V
Vehicle battery If the vehicle battery is selected instead of the leisure battery, then similar
warnings warnings to those described above are applied to the vehicle battery. The
vehicle battery low warning level is 10.9V
Engine running When the engine is started the
system power will be turned off
Step extended and engine
started
Step extended
Step jammed or obstructed
Type
Message on screen and 60 second audible
beep
Message on screen and 60 second audible
beep
Message on screen and 60 second audible
beep
Message on screen and 60 second audible
beep. If no action taken after 30 seconds
then the system will switch the power off to
prevent severe discharge of the battery
Message on screen and repeated beeps
from the control panel. The power is
automatically turned off. The beeping will
not stop until the fault is cleared.
Message on screen stating 'engine running'.
Message on screen and warning buzzer
