Thetford Toilet - Swift Group Select 122 Owner's Handbook Manual

Thetford toilet

Cassette C260S
Your motorhome is fitted with a Thetford
C260 toilet, which is plumbed directly into
the motorhome water system, and does not
have its own flush tank. Using the C260 model
number, please read the user instructions for
the toilet, which are available from the following
location:
https://www.dropbox.com/s/
uwbfrtwcium021z/C260%20UM%20EN.
pdf?dl=1
If you are unable to view the documents on
line, please contact the supplier, your dealer or
Swift for an electronic or paper copy.
THETF ORD T OILE T / W INDOW S
Windows
To open, turn knobs anti-clockwise and open
catches. Swivel the window pane open to the
desired position and close knobs clockwise to
lock in the open position.
To close, reverse the operation.
All opening windows have two catch positions.
The first position is for ventilation the second
seals the window from ventilation and rain.
Operating instructions for blinds
To operate the Blind
The blind is housed at the bottom of the
cassette and flynet at the top. The metal bar
can be pulled up or down as required. On
some models there is a silver retaining clip that
holds the two together. Rock the clip back to
release.
105
