MOTION SENSOR
INSTALLATION GUIDE
STEP 1: INSTALL BATTERY
To open the
battery cover,
use a
flathead
screwdriver in
the recessed
Te h
slot as shown.
Remove the packing tape, if present,
from the battery cover and install the
CR2 battery with polarity as shown.
If the battery is pre-installed, simply
remove the plastic pull tab.
STEP 2: INSTALL DRIVER AND IDENTIFY
Install the device's driver:
MotionSensor_zb_nyce_3041.c4i
Download driver from:
www.nycesensors.com/support
or from Control4's online database
Copy to My Documents\Control4\Drivers
Open Composer and add device to project (Manufacturer = "NYCE")
Identify the device by pressing the button 4 times while its identify
window is open.
The device's 64-bit address should appear in the identify window's text
box.
STEP 3: VERIFY DEVICE AND CLOSE
Verify that the device is sensing motion.
The sensor requires a 3 minute "warm-up" time
before it will report motion.
The LED should flash red and motion should be
indicated in Navigator or Composer's List View.
Snap the battery cover into place.
