MOTION SENSOR
INSTALLATION GUIDE
STEP 1: INSTALL BATTERY
To open the
battery cover,
use a
flathead
screwdriver in
the recessed
Te h
slot as shown.
Remove the packing tape, if present,
from the battery cover and install the
CR2 battery with polarity as shown.
If the battery is pre-installed, simply
remove the plastic pull tab.
STEP 2: JOIN THE NETWORK
Users:
Refer to the instructions on your web portal or smart phone application
to join and configure the Motion Sensor.
Developers:
Refer to NYCE'S "ZigBee Device Messaging Specification" document for
details on how to join the Motion Sensor to the ZigBee network.
This document can be found on NYCE's Website Support page:
www.nycesensors.com/support/
STEP 3: VERIFY DEVICE AND CLOSE
Verify that the device is sensing motion.
The sensor requires a 3 minute "warm-up" time
before it will report motion.
The LED should flash red and motion should be
indicated on your web portal or smart phone
application.
Snap the battery cover into place.
Advertisement
Related Manuals for Nyce NCZ-3041-HA
Summary of Contents for Nyce NCZ-3041-HA
- Page 1 The LED should flash red and motion should be from the battery cover and install the indicated on your web portal or smart phone CR2 battery with polarity as shown. This document can be found on NYCE’s Website Support page: application. www.nycesensors.com/support/ If the battery is pre-installed, simply Snap the battery cover into place.
- Page 2 Sensor through the ZigBee network. sided tape provided. It can be installed on a flat surface or in a corner, vertically, horizontally or upside down. This document can be found on NYCE’s Website Support page: www.nycesensors.com/support/ Notes: Test the Sensor from the desired location before Orient the Motion Sensor for best use of its detection permanent installation.
