Web-based Quick Setup Wizard
6
Select the corret time zone for the modem router, and
then click NEXT.
Select the Connection Type given by your ISP and then
7
click NEXT. Here we use PPPoE/PPPoA as an example.

Troubleshooting

T1. How can I set my computer to Obtain an IP
address / DNS server address automatically?
For Mac OS X
1) Click the Apple icon on the upper left corner of the screen.
2) Go to "System Preferences -> Network".
3) Select Airport on the left menu bar, and then click Advanced for
wireless con guration; or select Ethernet for wired con guration.
4) In the Con gure IPv4 box under TCP/IP, select Using DHCP.
5) Click Apply to save the settings.
For Windows 7
1) Click "Start -> Control Panel -> Network and Internet -> View
network status -> Change adapter settings".
Right-click Wireless Network Connection (or Local Area
2)
Connection), and then click Properties.
Select Internet Protocol Version 4 (TCP/IPv4), and then click
3)
Properties.
4) Select Obtain an IP address automatically and Obtain DNS
server address automatically. Then click OK.
For Windows XP
1) Click "Start -> Control Panel -> Network and Internet
Connections -> Network Connections".
2) Right-click Wireless Network Connection (or Local Area
Connection), and then click Properties.
3) Select Internet Protocol (TCP/IP), and then click Properties.
4) Select Obtain an IP address automatically and Obtain DNS
server address automatically. Then click OK.
( For users unable to run the Resoure CD )
8 Enter the Username and Password provided by your ISP
and then click NEXT.
Record your PPPoE information here:
Username:
Password:
For Windows 8
1) Move your mouse to the lower right corner and click the Search icon
in the Popups.
2) Go to Apps, type Control Panel in the search box and press Enter.
3) Go to "Control Panel -> View network status and tasks > Change
adapter settings".
4) Right-click Ethernet, select Properties. Then double-click Internet
Protocol Version 4 (TCP/IPv4).
5) Select Obtain an IP address automatically and Obtain DNS server
address automatically. Then click OK.
T2. What can I do if I cannot access the Internet?
1) Check your cables and make sure they are all plugged in correctly,
including the telephone line, Ethernet cables and power adapter.
2) Check to see if you can log on to the web management page of the
modem router. The default address of the web management page is
http://192.168.1.1. If you can, try the following steps. (If you can
not, please refer to T1 to configure TCP/IP Properties and then try to
access the Internet again.)
3) Consult your ISP and make sure all the VPI/VCI, Connection Type,
account username and password are correct. If they are not, please
repleace them with the correct settings and try again.
4) If you still cannot access the Internet, please restore your modem
router to its factory default settings and reconfigure your modem
router following the instructions in this QIG.
5) Please feel free to contact our Technical Support if the problem still
exists.
9 The WLAN function is enabled by default. It is strongly
recommended to change the SSID (Wireless Network
Name) and set a Pre-Shared Key for network security.
Keep other settings by default, then click NEXT.
Disable Wireless Security is not recommended.
Record your wireless information here:
SSID(Wireless Network Name):
Pre-Shared key:
For the advanced con gurations, please refer to the User Guide at http://www.tp-link.com．
T3. How can I restore my modem router's con guration
to its factory default settings?
Once the modem router is reset, the current settings will be lost and you will
need to reconfigure the modem router. We strongly suggest you back up
the current settings before resetting the modem router. For more Backup
information, please refer to 4.6.3 Firmware on User Guide.
With the modem router powered on, use a pin to press and hold the RESET
button on the rear panel for 8 to 10 seconds before releasing it.
T4. What can I do if I forget my password?
Reset the modem router rst and then use the default user name and
password: admin/admin.
For more details about Troubleshooting and
Technical Support contact information, please
log on to our Technical Support website:
http://www.tp-link.com/en/support
10
Complete the con guration and click NEXT.
Quick Start has completed. Click CLOSE to make your
11
9 settings take e ect.
The basic settings for your modem router are
completed. Please open the web browser and try to log
on to http://www.tp-link.com to test your Internet
connection.
