IBM
Power System LC921
(9006-12C) Quick Install
IBM
Guide
®
IBM Power
System LC921 (9006-12C) Quick Install Guide
The IBM Knowledge Center is available online from: http://www.ibm.com/support/knowledgecenter/
POWER8/p8hdx/9006_12c_landing.htm.
v Read all precautions and instructions before you start working on key parts.
v Use normal electrostatic discharge (ESD) procedures when working on the system and parts. IBM
recommends wearing gloves and an anti-static wrist strap to avoid possible damage to the equipment.
9006-12C information: https://ibm.biz/9006-12CQR
9006-12C parts
Use this information to find the field-replaceable unit (FRU) part number.
After you identify the part number of the part that you want to order, go to Advanced Part Exchange
Warranty Service. Registration is required. If you are not able to identify the part number, go to
®
Contacting IBM
service and support.

Advertisement

loading

Related Manuals for IBM LC921

Summary of Contents for IBM LC921

  • Page 1 Read all precautions and instructions before you start working on key parts. v Use normal electrostatic discharge (ESD) procedures when working on the system and parts. IBM recommends wearing gloves and an anti-static wrist strap to avoid possible damage to the equipment.
  • Page 2 Rack final assembly Figure 1. Rack final assembly Table 1. Rack final assembly part numbers Units per Index number Part number assembly Description MCP-290- Slide rail kit - contains left and right slide rails and 00052-0N attaching screws MCP-290- Slide rail kit - contains left and right slide rails and 00052-0N attaching screws...

  • Page 3: System Parts

    System parts Figure 2. System parts Table 2. System parts Index number Part number Units per assembly Description Top cover assembly Screws PCIe adapters. Use the feature type of the adapter to find the FRU number in PCIe adapter information by feature type for the 9006-12C.
  • Page 4 Table 2. System parts (continued) Index number Part number Units per assembly Description PCIe adapter. Use the feature type of the adapter to find the FRU number in PCIe adapter information by feature type for the 9006-12C AOC-UR-i4XTF 1U UIO NIC PCIe adapter with integrated 4-port 10 GbE Base-T, Intel XL710, and CAPI Note: This PCIe adapter is also a PCIe riser.
  • Page 5 Table 2. System parts (continued) Index number Part number Units per assembly Description HDD-KIT-2A- 1.2 TB 10k (512 block size) 2.5 inch SAS disk drive ST1200S-IB001 HDD-KIT-2A- 1.8 TB 10k (512 block size) 2.5 inch SAS disk drive ST1800S-IB001 HDD-A2000- 2.0 TB 7.2K (512 block size) 3.5 inch SAS disk drive ST2000NM003401 or HDD-A2000-...
  • Page 6 Table 2. System parts (continued) Index number Part number Units per assembly Description BPN-SAS3-815TQ- Disk drive backplane Screws FAN-0141L4 Fan holder CPU 1 air baffle CPU 2 air baffle...
  • Page 7 Additional system parts Figure 3. Additional system parts Table 3. Additional system parts Index number Part number Units per assembly Description MEM-DR480L-049 8 GB, 2666 MHz 1RX4 DDR4 RDIMM* MEM-DR416L-066 16 GB, 2666 MHz 1RX4 DDR4 RDIMM* MEM-DR432L-028 32 GB, 2666 MHz 2RX4 DDR4 RDIMM* MEM-DR464L-SL01- 64 GB, 2666 MHz 4RX4 DDR4 RDIMM* ER26...

  • Page 8: Rear Ports

    Table 3. Additional system parts (continued) Index number Part number Units per assembly Description SSD-DM128- 128 GB SATA drive on module (DOM) SMCMVN1 AOM-TPM-T650V Trusted platform module (TPM) card MBD-P9DSU-C-P System backplane Screws 16 core 2.9 GHz system processor module 20 core 2.9 GHz system processor module SNK-P0052P-IB001 Heat sink kit (includes heat sink and thermal interface...
  • Page 9 Figure 5. Removing a power supply from the system Figure 6. Releasing and opening the cover Figure 7. Removing a front drive Figure 8. Removing the 3.5-inch drive from the tray...
  • Page 10 Figure 9. Removing the 2.5-inch drive from the tray Figure 10. Removing the disk drive backplane and screws Figure 11. Disconnecting the drive signal and power cables...
  • Page 11 Figure 12. Removing the fan holder Figure 13. Removing a fan Figure 15. Aligning the fan holder Figure 14. Disconnecting the fan cable...
  • Page 12 Figure 17. Two processor memory plugging sequence Figure 16. Removing the memory Figure 18. 9006-12C PCIe adapter positions Figure 19. Removing the PCIe riser...
  • Page 13 Figure 21. Removing the PCIe riser cards from the adapter cage Figure 20. Removing the UIO Network screws Figure 22. Removing a PCIe adapter from position 3 of the riser Figure 23. Removing the GPU from the riser...
  • Page 14 Figure 24. Processor socket screws on bottom of chassis Figure 25. Screw locations Figure 26. Loosening heat sink load arm screw...
  • Page 15 Figure 27. Removing the heat sink Figure 29. Installing the system processor module Figure 28. Placing the processor at an angle on the top cover of the packaging...
  • Page 16 Figure 30. Installing the heat sink Figure 31. Tightening the load arm screw Figure 32. Time-of-day battery location This September 14, 2017 edition applies to IBM Power Systems servers that contain the POWER8 processor and to all associated models. © Copyright IBM Corporation 2017.
