- Page 3 Thank you for choosing one of our products. We hope you will get the very best performance from this appliance. Before using this appliance, carefully read the warnings contained in this instruction manual, since these are important instructions for its safe installation, use and maintenance. Carefully conserve this manual for future consultation.
- Page 4 GENERAL WARNINGS - INSTALLATION / REPAIRS THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR ANY DAMAGE TO PEOPLE OR ITEMS CAUSED BY INCORRECT INSTALLATION OR IMPROPER, WRONG OR ABSURD USE OF THE APPLIANCE. o Warning: earth connection is required by law. o HOOK-UP: check that the operating specifications on the label correspond with those in the place of installation.
- Page 5 o Do not touch the appliance with damp or wet hands or feet. o Do not pull on the power supply cable, or the appliance itself, to remove the plug from the mains power socket. o Hot grease and fat catch fire easily. Be careful. Never try to put out burning oil or fat with water (danger of explosion);...
- Page 6 Before hooking-up to the mains supply, make sure that: - the socket has a ground connection and complies with legal regulations; - the socket is able to withstand the oven's maximum power capacity indicated on the features typeplate (see below); - The power supply voltage is within the values listed in the electrical characteristics label (see below);...
- Page 7 Installation scheme:...
- Page 8 Embossed walled oven cooking suggestions: For time and temperature indications for different foods, consult the RECIPES table Cooking Cooking Cooking Together Name of Dish Level Function Temperature Time Cannelloni VENTILATED 180° 00h.45’ Flans: STATIC Lasagne 160° 00h.50’ VENTILATED Quiches Ventilated 180°...
- Page 9 ELECTRONIC PROGRAMMER FUNCTION Increments temperatures values Decrements temperatures values Time Increments values (timings, programs) Turns on the oven (On/Off) Chlidren Lock if pressed > 4 seconds Timing Edit menu (Minute minder, duration, end of cook) Time Decrements values (timings, programs) Increments programs values Decrements programs values...
- Page 10 SEQUENCE ASSOCIATED TO (5) key Display after IMPULSE Display after press 2 sec. Bell Icon “ 0:00” as default value, [ ) ] otherwise the actual value Cooking Pot Icon “ 0:00” as default value, [ dur ] otherwise the actual value Cooking Pot Icon Time of day as default value, [ End ] only if present a...
- Page 11 TEMPERATURE DISPLAY (A) It shows the temperature setpoint and provides also some icons and a temperature bar-graph indication. CLOCK DISPLAY The 4-digit display (B) shows Timings, Durations, and Messages. It integrates also 3 icons ( ) 3 A ) representing the Timings operating states. COOKING POT ICON 3 It is lit-up to indicate that a cooking fuction is operating, even in manual mode.
- Page 12 OPERATING INSTRUCTIONS At first power-up, the display shows “00:00” the clock flashing, incrementing by 1 unit each minute. The oven is inibited, and the only two allowed operations are: - Time of Day setting, by means of + (3) / - (4) - Oven turn-on (the currently shown time of day is automatically accepted) by means of [OnOff] TIME OF DAY SETTING...
- Page 13 TIME CONTROLLED COOKING Turn on the oven, select a cooking mode, check the temperature in the display and after press (5) 2 times, the clock display shows “ dur”. Edit the value by means of + (3) and - (4) ranging from a minimum of 0h:00m and a maximum of 10h:00m.
- Page 14 ETC CLEANING FUNCTION Pour 0.4 - 0.5 litres of soapy water directly on the drip pan. Insert the drip pan in the bottom level. Select the cleaning function “Etc” and after 20 minutes the cycle goes off. Once the default time has expired, it is possible to clean the oven with a soft sponge (dirt is easy to remove since it was softened during the cleaning cycle).
- Page 15 PREHEAT BAR-GRAPH The bar shows the preheating status. Start : 1° flashing; 2° ,3° ,4° off If >25% : 1° on, 2° flashing; 3° ,4° off If >50% : 1° ,2° on; 3° flashing; 4° off If >75% : 1° ,2° , 3° flashing; 4° off If 100% : 1°...
- Page 16 TANGENTAL BLOWER HANDLING COOKING MODE SELECTION The blower turns on, no matter which is the cavity temperature, after 15 minutes the function is started, or even before if the cavity Probe temperature is > 130° C COOKING MODE STOPPING (OFF, STAND-BY) The blower turns off, no matter which is the cavity temperature, after 25 minutes the oven turned off, or even before if the cavity Probe temperature is <...
- Page 17 PROGRAMMER AND COOKING FUNCTIONS The temperature shown on the display can be changed using the +/- buttons on the left, with variations of 5° C, from a minimum of 40° C up to a maximum of 250° C. The ° C symbol flashes upon reaching the desired temperature.
- Page 18 TRADITIONAL COOKING + FAN This type of cooking is a combination of conventional and ventilated. It is ideal for bread, focaccia, and lasagne. The oven does not require preheating (except for pizza and focaccia). Invert the position of the dishes in the oven a few minutes prior to the end of the cooking time.
- Page 19 FAN + DOUBLE GRILL Heat is directed onto the dishes from the upper heating elements towards the bottom. The action of the fan, combined with the action of the grill, allows for quick, thorough cooking of special foods. This cycle is ideal for browning and sealing juices and flavour in foods, for example, steak, hamburgers, vegetables, etc.
- Page 20 SYSTEM FAULTS PROBLEM SOLUTION The oven does not work Check whether the omnipolar switch or any residual-current circuit breaker (cut- out) of the electrical system is off. In case of problems with the electrical system, consult a qualified electrician. If the oven still does not work after resetting the omnipolar switch and/or residual current circuit breaker, contact an Authorized Service Centre.
- Page 21 ERROR CODES TABLE The electronics system continually performs a series of diagnostic test. If some parameters are incorrect, the control unit deactivates the function and display an error code. The heating elements are turned off, including the fan inside the cooking chamber.
- Page 22 ...
- Page 23 DISASSEMBLY OF SIDE GRILLS ON OVENS WITH SMOOTH SIDES Remove, one at a time, the side grills G from their mounting holes. REASSEMBLY OF SIDE GRILLS Insert the grills one at a time. Pay attention to the groove on the grill. The grill must be correctly inserted in the correct holes inside of the oven.
- Page 24 To replace the rectangular bulb, proceed as follows: 1. Unplug the appliance from the electrical power supply. 2. Check that the oven is at room temperature, otherwise wait for it to cool. 3. Remove the side grill. 4. Remove glass using screwdriver.E.
- Page 25 With the door with the internal glass panel, the glass can only be cleaned towards the inside of the oven. The "vertical frame" door can be disassembled to enable the glass to be cleaned, it is possible to take off the upper part by using a coin, please see the figure below.
- Page 26 2 glass panels version After having extracted the upper part, slide out the glass, please see the figure below, and re-install it by reversing the procedure. 3 glass panels version After having extracted the upper part, slide out the external glass panel, and then the internal one, please see the figure below, and re-install it by reversing the procedure.
- Page 27 removable glass version TECHNICAL SERVICE AND SPARE PARTS If the recommended checks do not resolve the problem, contact an Authorized Service Centre, indicating the type of fault, appliance model and serial number located on the oven identification label. The plate is located in the outer part of the oven and is visible when the door is open.
