Summary of Contents for Euro Appliances EP500UW
- Page 1 Freestanding Electric Oven Instructions for installation and use EP500UW...
- Page 2 Please read all instructions before using this appliance. This book contains valuable information about operation, care and service. Keep this booklet in a safe place for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the booklet is supplied with the appliance in order that new owner can be acquainted with the functioning of the appliance and relevant warnings.
- Page 3 The electrical safety of this appliance can only be guaranteed if the cooker is correctly and efficiently earthed, in compliance with current regulations on electrical safety. Always ensure that the earthing is efficient if you have any doubts call in a qualified electrician to check the system.
- Page 4 Never use flammable liquids such as alcohol or gasoline, etc. near the appliance when it is in use. Danger of fire: do not store items on the cooker surfaces. When using small electric appliances near the hob, keep the supply cord away from the hot parts.
- Page 5 cabinet one side or both as well as in a corner setting. It can also be used free- standing. The appliances can be installed next to furniture units which are no taller than the top of the cooker hobs. If the cooker is placed touching walls or sides of neighbouring cabinets, these must be capable of withstanding a temperature rise of 50 C above room temperature For a correct installation of the cooker the following precautions must be followed:...
- Page 6 Electrical connection WARNING -THIS APPLIANCE MUST BE EARTHED. The electric Power supply voltage and frequency: 220-240V /380-415 3N, 50/60Hz. cooker without a power supply cable. The cooker is designed to operate on an electricity supply which conforms to the electrical data shown on the Rating label . The cooker can be connected to the mains only after removing the back panel of the cooker itself with a screwdriver.
- Page 7 When used properly your appliance is completely safe but as with any electrical product there are certain precautions that must be observed. PLEASE READ PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE. Safety Information Always Turn controls when you have finished cooking and when not in use. Stand back when opening an oven door to allow any build up of steam or heat to disperse.
- Page 8 Never use steam cleaners In the event of a chip pan fire or any other pan fire. TURN OFF THE COOKER APPLIANCE AT THE WALL SWITCH. COVER THE PAN WITH A FIRE BLANKET , this will smother the flames and extinguish the fire.
- Page 9 Symbol Function description Oven Lamp: Enables the user to observe the progress of cooking without opening the door. Oven lamp will lighting for all cooking functions, for the cooker with this optional function. T o p heat: A concealed element in the t o p of the oven provides a more concentrative heat to the base of food without blowing.
-
Page 10: Shelf Placement Warning
SHELF PLACEMENT WARNING: To ensure the oven shelves operate safely, correct placement of the shelves between the molding liner is imperative. This will ensure that during careful removal of the shelf or tray, hot food items should not slide out. Never: Use gauze, metal pan diffusers, asbestos mats and stands e.g. - Page 11 Use utensils with recessed, scrolled or ridged bases. Use a utensil which has a base concavity greater than 1mm as this will reduce the performance of the hob. Use a utensil with a convex base. Use glass ceramic utensils. The oven temperature setting knob can only be rotated clockwise from the OFF position.
- Page 12 Removing the door for easier cleaning We recommend you have someone to assist you during removal of the door Open the door completely The door hinge has a small latch Lift the latch on both hinges Lift the door slightly as if closing and then with both hands supporting the door;...
- Page 13 Voltage and Frequency of Power Supply: This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste. There are separate collection systems for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product.
