4.3 Monitor Tour Programming
A monitor tour is a temporary sequence of cameras programmed
exclusively for the called monitor. A monitor tour may contain up to
64 cameras, and each video input is displayed on the monitor for a
pre-defined period of time (Dwell Time).
Press the HOLD button to hold a currently running monitor tour.
While the monitor tour is in hold status, press the NEXT button to
display the next video input in the pre-programmed sequence, and
press the RUN button to start the monitor tour again. The on-screen
Status Line displays the Dwell Time for each video input.
To program a monitor tour:
1. Call the desired monitor.
2. Place the key switch in PROGRAM position.
3. Enter "62", then press the PROG button. This puts the system in
Tour Programming mode.
4. Call the camera to be first displayed in the tour.
5. Enter "1" to "60" for the desired dwell time in seconds for the
on-screen camera. To stop and hold the tour on that camera, enter
"61".
6. Press the PROG button to set the dwell time for the on-screen
camera to the value entered. The on-screen display changes to
show the dwell time (or HOLD if "61" was entered in Step 5). If
no more cameras are to be included in the tour, skip to step 9;
otherwise, continue with Step 7.
7. Call the next camera to be included in the sequence. Cameras
need not to be inserted in the tour in numerical order.
Note: Do not enter "62, PROG" during the following steps or
while modifying a monitor tour. It removes all previously
programmed cameras from the tour and necessitates tour
reprogramming.
8. Repeat Step 4, 5, 6 and 7 until all the cameras to be included in
the tour have been programmed.
9. Press the HOLD or RUN button to exit the Monitor Tour
Programming mode. The HOLD button leaves on the monitor the
input from the last camera programmed for the tour. The RUN
button switches the picture to the next camera in the tour and
initiate the tour sequence.
To re-program a single camera in a monitor tour:
1. Press the NEXT button until the desired camera is displayed on
the monitor, and then press the "HOLD" button.
2. Enter "0" and press the PROG button,
3. Enter the desired dwell time (1-60).
4. Press the PROG button.
5. Press the HOLD or RUN button to exit the Programming mode.
CAUTION: A system tour has a priority over a monitor
tour. Therefore, calling a system tour to a monitor clears
the current tour programmed for that monitor.
EXAMPLE: Programming a 3-camera monitor tour:
Place the key switch in PROGRAM position, and then proceed the
following steps:
24
1. Enter "62" and then press the PROG button to clear the
previously programmed monitor tour and access the Monitor
Tour Programming mode.
2. Enter the following key combinations to program the monitor
tour:
"1, CAM" (Includes Camera 1 to be the first camera in the tour.)
"1, PROG" (Sets the Dwell Time for Camera 1 to be 1 second.)
"2, CAM" (Includes Camera 2 to be the second camera in the
tour.)
"2, PROG" (Sets the Dwell Time for Camera 2 to be 2 seconds.)
"3, CAM" (Includes Camera 3 to be the third camera in the tour.)
"3, PROG" (Sets the Dwell Time for Camera 3 to be 3 seconds.)
3. Press the RUN button to exit the Monitor Tour Programming
mode and run the monitor tour.
While a tour is running, press the NEXT or RUN button will
change the running direction of the tour. The on-screen Status Line
will display the dwell time of the current camera. If a tour runs in
the forward direction, an "F" will be displayed beside the dwell
time; if a tour runs in the reverse direction, an "R" will be displayed
instead. Press the HOLD button to stop a running tour when
necessary.
4.4 Setting Date Format/Setting Day of the Week
V2040 provides three optional date formats:
MM/DD/YY (default)
DD/MM/YY
YY/MM/DD
To change the default date format:
1. Place the key switch in PROGRAM position.
2. Enter the following F2 code combinations:
"21, F2" /"41, F2"for MM/DD/YY
"22, F2"/"41, F2" for DD/MM/YY
"23, F2"/"41, F2" for YY/MM/DD
"24, F2"/"44 , F2" to change format among the 3 types above
3. Place the key switch in OPERATE position.
To set the day of the week:
1. Place the key switch in PROGRAM position.
2. Enter the following F2 code combinations on the keyboard:
"60, F2" –to display the day of the week
"61, F2" - Sunday (SUN)
"62, F2" - Monday (MON)
"63, F2" - Tuesday (TUE)
"64, F2" - Wednesday (WED)
"65, F2" - Thursday (THR)
"66, F2" - Friday (FRI)
"67, F2" - Saturday (SAT)
"70, F2" – to display the software version information
3. Place the key switch in OPERATE position.
