- Page 1 Usermanual Paper resp. Leather Moisture Meter Version 2.2_en © Schaller GmbH 2005...
-
Page 2: Quality Information
CE norms EN50081 and EN50082. The function of your instrument has been examined and calibrated before delivery. Application P2: Mainly for very strong paper, packing paper, cardboard P4: Mainly for paper used for offset printing LM5: mainly for leather... -
Page 3: Measuring Procedure
Measuring procedure Exact measuring results can best be achieved by adjusting the measuring instrument to the respective product temperature. So you should store the device near the object you wish to measure. A temperature difference of more than 5 ° C results in a falsified measured value. - Page 4 How to choose type of product Since there is no unified manufacturing process of the measuring products the adjustment of the switch can not be standardized. But there is always the possibility of having your device calibrated by Messtechnik Schaller GmbH (Ltd.).
- Page 5 : New moisture value for comparison measurement Now insert the switch position in the table. Please note: Messtechnik Schaller GmbH (Ltd.) provides special versions of P2, P4 and LM5 adapted to certain products. Refer to additional information on leather, page 11. Version 2.2_en...
-
Page 6: Measuring Method
Yet it is not possible to develop a measuring device that is ideal under every single condition; even P2, P4 and LM5 have a certain limited range to provide optimum results. In order to minimize incorrect applications resulting from that fact we have provided you with a list. -
Page 7: Measuring Principle
8 x 5 cm 7 x 4,5 cm Measuring instrument P2, P4 Measuring plate 8cm long x 5cm broad x 1,3cm depth Measuring plate 7cm long x 4,5 cm broad x 0,5cm depth Caution! When the material thickness is below a certain limit, the measuring result is falsified. -
Page 8: Exclusion Of Liability
Exclusion of liability The producer can not be made liable for any measuring errors and the damage that might result from it. This measuring principle is a quick measuring procedure which can be influenced by product and user-specific margin conditions. Therefore it is recommended to carry out a plausibility check of the measured values. - Page 9 Switch value adjust readjust position tolerance tolerance Value when held up in the air at switch position 1 is: P2= 1.3% und P4= 2.5% range of adjustment tolerance by the plant 0.6% Version 2.2_en Schaller GmbH Page 9...
- Page 10 Tcv = displayed value + (ambient temperature - 20° C) x x Tcf P2: Tcv= 6,1 + (28 – 20) x 0,04 results 6,4% If your value is beyond the set range of adjustment tolerance a new adjustment by the factory is necessary.
- Page 11 P2:1.3%, P4: 2.5%, LM5: 3.7%. Again the temperature correction value must be taken into consideration. Put on the serial number tag again, insert the battery and close the lid.
- Page 12 P2 Examination table Copy this table and fill in the displayed values – without temperature correction – and the ambient temperature. Enclose a copy of the data if the instrument should be adjusted again by the factory. serial number measuring instrument:_____________ serial number proof plate:______________ temperature :______°...
- Page 13 P4 Examination table Copy this table and fill in the displayed values – without temperature correction – and the ambient temperature. Enclose a copy of the data if the instrument should be adjusted again by the factory. serial number measuring instrument:____________ serial number proof plate:_____________ temperature :______°...
- Page 14 LM5 Examination table Copy this table and fill in the displayed values – without temperature correction – and the ambient temperature. Enclose a copy of the data if the instrument should be adjusted again by the factory. serial number measuring instrument:____________ serial number proof plate:_____________ temperature :______°...
-
Page 15: Technical Data
P2: 3-10% moisture of paper P4: 3-8% moisture of paper LM5: 8-20% moisture leather indication of % refers to wet weight P2, P4: switch position LM5: switch position 2 working temperature 5° C to 35° C temperature compensation P2:0,04%/° C ,P4:0,03%/° C LM5: 0,05%/C°... -
Page 16: Technical Support
Technical Support Max-Schaller-Straße 99 A – 8181 St.Ruprecht an der Raab Tel +43 (0)3178 28899 Fax +43 (0)3178 28899 - 902 E-Mail support@humimeter.com http://support.humimeter.com your local retailer date / stamp Page 16 Schaller GmbH Version 2.2_en...
