VISTEK V6155 Dual HD/SD SDI
Distribution Amplifier
Dual HD/SD SDI DISTRIBUTION
INSTALLATION and OPERATION
© Snell Ltd.
Filename:
V6155om_02.doc
Issue:
02
Date:
November 2009
Snell Ltd.
Hartman House
Danehill
Lower Earley
Reading
Berkshire, RG6 4PB
ENGLAND
Tel.
+44 (0) 118 986 6123
Fax.
+44 (0) 118 975 5787
Web:
www.snellgroup.com
HU-V6155
V6155
AMPLIFIER
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Snell VISTEK V6155
Summary of Contents for Snell VISTEK V6155
-
Page 1: Installation And Operation
VISTEK V6155 Dual HD/SD SDI Distribution Amplifier V6155 Dual HD/SD SDI DISTRIBUTION AMPLIFIER INSTALLATION and OPERATION © Snell Ltd. Filename: V6155om_02.doc Issue: Date: November 2009 Snell Ltd. Hartman House Danehill Lower Earley Reading Berkshire, RG6 4PB ENGLAND Tel. +44 (0) 118 986 6123 Fax. -
Page 2: Table Of Contents
VISTEK V6155 Dual HD/SD SDI Distribution Amplifier Contents DESCRIPTION..................3 INSTALLATION ..................4 2.1. REAR PANEL CONNECTIONS..............4 2.2. CONNECTIONS ..................4 2.3. FRONT PANEL ................... 5 2.4. POWER CONSUMPTION ................6 2.5. INSERTION DELAY ..................6 2.6. HARDWARE ....................6 2.7. -
Page 3: Description
VISTEK V6155 Dual HD/SD SDI Distribution Amplifier DESCRIPTION The V6155 is a Dual SDI Distribution Amplifier which operates at both HD and SD data rates. Due to limitations on the rear panel one amplifier has 4 outputs, while the second has 3 outputs. Each amplifier automatically detects the input signal as SD or HD, and has a reclocker. -
Page 4: Installation
VISTEK V6155 Dual HD/SD SDI Distribution Amplifier INSTALLATION 2.1. REAR PANEL CONNECTIONS V16HR3F 2.2. CONNECTIONS SIGNAL SOURCE COMMENTS A I/P CH A - SDI Video I/P Sourcing cable length up to 250m A1, A3 CH A – O/Ps 1 and 3... -
Page 5: Front Panel
VISTEK V6155 Dual HD/SD SDI Distribution Amplifier 2.3. FRONT PANEL INDICATORS DESCRIPTION Onboard regulated power is present Short blips to indicate access from the remote control system. A Rack Controller must be fitted to the Chassis. A + SD Indicates Channel A has an I/P at an SD data rate... -
Page 6: Power Consumption
VISTEK V6155 Dual HD/SD SDI Distribution Amplifier 2.4. POWER CONSUMPTION Module Power V6155 <5W 2.5. INSERTION DELAY SIGNAL DELAY <5ns <20ns 2.6. HARDWARE The figure below shows diagrammatically the main board of the V6155 along with some components of interest. The shaded area at the rear of the board represents the IO Daughter Board. -
Page 7: Asi Signals
VISTEK V6155 Dual HD/SD SDI Distribution Amplifier ASI SIGNALS Although the V6155 is essentially a SDI DA, it can be used for ASI signals on some outputs. The main difference between an ASI signal and a pure SDI signal is that SDI is polarity independent while ASI signals are not.
