- Page 1 User Instruction Manual IQFDA30 3G/HD/SD-SDI Re-clocking Distribution Amplifier with Fiber I/O snellgroup.com...
-
Page 2: Information And Notices
Information in this manual and software are subject to change without notice and does not represent a commitment on the part of Snell Limited. The software described in this manual is furnished under a license agreement and can not be reproduced or copied in any manner without prior agreement with Snell Limited. -
Page 3: Table Of Contents
5.8.2 Configure Type ..........24 © Issue 1 Rev 2 Page 3 2013 Snell Limited... -
Page 4: Introduction
1. Introduction 1.1 Description The IQFDA30 provides HD-SDI 3 Gbit/s, 1.5 Gbit/s, or 270 Mbit/s SD-SDI inputs with both SDI and Fiber optic outputs in a single-width package. Its 80m 3G, 170m HD, and 300m SD input equalization performance and non re-clocking distribution of wide-band signals make it ideal for all distribution applications. -
Page 5: Feature Summary
IQFDA30 www.snellgroup.com Introduction 1.3 Feature Summary The IQFDA30 provides the following features: • Single-channel 3 Gbit/s SDI, HD-SDI, and SD-SDI re-clocking distribution amplifier. • Provides distribution for DVB-ASI and other wide-band signals. • Equalizes up to 70 m at 3 Gbit/s, 170 m at 1.5 Gbit/s and 350 m at 270 Mbit/s when using Belden 1694A cable. -
Page 6: Enclosures
“B” order codes only. 1.6.2 A-style Enclosures Enclosure order code: IQH1A-S-P Enclosure order codes: IQH3A-S-0, IQH3A-S-P Enclosure order codes: IQH3A-E-0, IQH3A-E-P, IQH3A-0-0, IQH3A-0-P Enclosure order code: IQH1A-S-P © Issue 1 Rev 2 Page 6 2013 Snell Limited... -
Page 7: Technical Specification
Inputs and Outputs Signal Inputs SDI Inputs 1 x 3G/HD/SD-SDI Connector / Format BNC / 75 Ohm panel jack on standard Snell connector panel Conforms to video standards SMPTE 297-2006 SMPTE 424M (HD level A/B) SMPTE 292M (HD) SMPTE 259M-C (SD) - Page 8 3 Gbit/s SDI, SMPTE 424M 1.5 Gbit/s HD-SDI, SMPTE 292M 270 Mbit/s SDI, SMPTE 259M-C / DVB-ASI Connector / Format BNC/ 75 Ohm Standard Snell screw terminal LC singlemode SFP © Issue 1 Rev 2 Page 8 2013 Snell Limited...
- Page 9 Up to 30 Km @ 3 Gbit/s Up to 21 Km @ 1.5 Gbit/s Up to 10 Km @ 270 Mbit/s Power Consumption Module Power Consumption 4 W Max (A frames) 4 PR Max (B frames) © Issue 1 Rev 2 Page 9 2013 Snell Limited...
-
Page 10: Connections
IQFDA30 www.snellgroup.com Connections 3. Connections This section describes the physical input and output connections provided by the IQFDA30. 3.1 SDI Input Serial digital input is made to the unit via a BNC connector which terminates in 75 Ohms. 3.2 SDI Outputs... -
Page 11: Card Edge Leds
Both LEDs illuminated: 3 Gbit/s • Left LED illuminated: 1.5 Gbit/s • Right LED illuminated: 270 Mbit/s • Both LEDs off: Rate unknown Green Illuminated Input SFP Rx A selected. © Issue 1 Rev 2 Page 11 2013 Snell Limited... -
Page 12: Operation Using The Rollcall Control Panel
Operation Using the RollCall Control Panel 5. Operation Using the RollCall Control Panel The IQFDA30 will dynamically configure itself depending on rear and SFP options. The Note: RollCall control panel will change to reflect the current product configuration. The screens shown in this section are for guidance and reference only, and may be slightly different to those on your module. -
Page 13: Input
Select Mute On Inp Err to apply a mute to the output if any rate other than those specified as valid in the Input 1 and Input 2 sections is detected. Select Mute to manually apply a mute to the output. © Issue 1 Rev 2 Page 13 2013 Snell Limited... -
Page 14: Sfp
Rx Power State: Displays the state of the received signal (options include OK, WARN:HI, WARN:LO, FAIL:LO and FAIL:HI). • Rx Power: Displays the signal level received at the input (in dBm). © Issue 1 Rev 2 Page 14 2013 Snell Limited... -
Page 15: Memory 1-16
The Last Recalled Memory pane displays the most recently recalled memory. If any of the settings have been changed since it was recalled, an asterisk will be displayed after the memory name. © Issue 1 Rev 2 Page 15 2013 Snell Limited... -
Page 16: Save Memory Name
• In the Save Memory Name field, type the new memory name, and then click the S button. To return the memory to its default preset value, click P button. © Issue 1 Rev 2 Page 16 2013 Snell Limited... -
Page 17: Logging
The Logging Misc screen displays the current log information about the unit’s basic parameters. 5.5.2 Logging Inputs The Logging Inputs screen is used to select which fields should be enabled for each of the serial inputs. © Issue 1 Rev 2 Page 17 2013 Snell Limited... -
Page 18: Logging Sfp
IQFDA30 www.snellgroup.com Operation Using the RollCall Control Panel 5.5.3 Logging SFP The Logging SFP screen is used to select which fields should be enabled for each of the SFP inputs. © Issue 1 Rev 2 Page 18 2013 Snell Limited... -
Page 19: Log Field Descriptions
• WARN:LO • FAIL:LO • FAIL:HI OUTPUT_N_TX_POWER= The power level of the TX input, in dBm. OUTPUT_N_WAVELENGTH= The wavelength of the transmitted output signal. OUTPUT_N_LASER_BIAS= The bias level, in mA. © Issue 1 Rev 2 Page 19 2013 Snell Limited... - Page 20 • • WARN:HI • WARN:LO • FAIL:LO • FAIL:HI N should be replaced with the respective SFP/output identifier, for example, 1 for an SFP Note: and B for an output. © Issue 1 Rev 2 Page 20 2013 Snell Limited...
-
Page 21: Rolltrack
LASER Bias current below limits. RX N Power OK Receive power is within limits. RX N Power High Receive power is above limits. RX N Power Low Receive power is below limits. © Issue 1 Rev 2 Page 21 2013 Snell Limited... -
Page 22: Address
The message is not being sent. The message is being sent. Internal Type Error Inconsistent behavior. Please contact your local Snell agent. 5.6.7 RollTrack Status A message is displayed here to indicate the status of the currently selected RollTrack index. -
Page 23: Setup
To change the name of Input 1 or Input 2, type the name in the text field and click S. To return the name to its factory default, click P. © Issue 1 Rev 2 Page 23 2013 Snell Limited... -
Page 24: Sfp Setup
When changing an SFP, the module needs to be restarted in order for the SFP to become Note: active. Before configuring the SFP, ensure that the correct SFP is installed. © Issue 1 Rev 2 Page 24 2013 Snell Limited...
