3.) Interface Description

Hardware Interface

Power Cable Input:
Power Output
RJ45 Ethernet:
RESET
Status Indicator
The Power Input locates on the back of
the device.
The Power output is on the top of the
device. Simply plug & play in the
device that you would like to power
control. (Comes in different plug
standards)
Plug in the RJ45 Ethernet cable to the
Ethernet port
To revert to manufacturer default, hold
down for 7-9 seconds until you hear 2
long beeps.
Red Status Indicator: Output port is
set to off
Green Status Indicator: Output is On
- 8-
Ref#92550806002
