Aviosys IP Power 9658 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IP Power 9658 series
(9658S / 9658T)
User Manual
Version: V1.00
( Firmware Version: 1.00)
Date Released: August. 2024
Warning: Any changes made to this equipment without permission may cause damages to the device
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP Power 9658 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aviosys IP Power 9658 Series

Summary of Contents for Aviosys IP Power 9658 Series

  • Page 1 IP Power 9658 series (9658S / 9658T) User Manual Version: V1.00 ( Firmware Version: 1.00) Date Released: August. 2024 Warning: Any changes made to this equipment without permission may cause damages to the device...
  • Page 2 IMPORTANT NOTICE: 1. IP Power 9658 was designed for indoor use, we carry no responsibility for possible damages caused by outdoor use, especially in the rain. 2. Please use the power adapter provided by the dealer, we carry no responsibility for the possible damage from using power adapters not provided by us.

  • Page 3: Table Of Contents

    Table of Content 1. INTRODUCTION ....................5 2. PRODUCT INFORMATION ................6 2.1 Features ................................. 6 2.2 Specification ................................7 2.3 Minimum System Requirements ......................... 7 2.4 Package Contents ..............................8 2.5 Interface ................................. 8 3. SETTING UP YOUR DEVICE ................ 10 3.1 Before Starting ..............................
  • Page 4 5.1 CGI HTTP Commands ............................. 50 5.2 Telnet Control ..............................51 6. FAQ : ......................52...

  • Page 5: Introduction

    1. Introduction IP Power 9658 is a new generation of the Power Distribution Unit (PDU) & Remote Power Control (RPC) system which add "Active Spike Filter Design” in the hardware design and make the system with higher grade stability. With embedded web server and HTTPS protection, 9658 supports higher grade security as working on Internet.

  • Page 6: Product Information

    11. Specific software developed by Aviosys and provided free of charge - IP Power Center - control multiple Aviosys IP devices in same AP. - CNT software ( Cross Network Technology )- allows user eliminate set up work on any Router without port forwarding , simply Plug &...

  • Page 7: Specification

    2.2 Specification ⚫ Power input : 100 - 240VAC , 50-60Hz , ⚫ Maximum loading of each output: 10A ⚫ Maximum of Total loading : 10A / 240VAC , 15A / 100VAC ⚫ Fuse protection : 10A / 250VAC ( with spare fuse in socket ) ⚫...

  • Page 8: Package Contents

    2.4 Package Contents 9658 Unit x 1 Content in the package: Online CD Note 2.5 Interface Front View From Left to right : LED of Outlet Status The outlet status #1 ~ #4 Indicator - Green light ON as outlet ON. Light OFF as outlet OFF Reset To set back the setting to factory default, please keep pressing the reset button with a sharpen pin and release the...

  • Page 9: Rear View

    Rear View ⚫ 9658S : ⚫ 9658T : Interface from Left to right : Connect up to 4 individual outlets to be controlled by the 9658. Ports 4 outlets sequence as 4 / 3 / 2 / 1 . ⚫ 9658S : IEC320 socket , 10A / 240VAC ⚫...

  • Page 10: Setting Up Your Device

    3. Setting up your device 3.1 Before Starting *Before setting up the device make sure of the following: 1.) All the package contents are all included if anything is missing please contact the dealer where the device was purchased from. 2.) Check the power input cable is working correctly.

  • Page 11: Software Installation

    3.3 Software Installation www.aviosys.com/cd Please move to . The note with this online CD link comes with the package. IP Power Software: (1) IpEdit (Required) (2) IP Power Center *( For multiple IP Power devices control purpose ) Please download the IPC-98 series, IPC-98 series support IP9658 to operate and update.

  • Page 12: Lan Connect By Ip Search Software " Ipedit

    If you already have IPEDIT, please check your current version, 9658 only support version 1.2.8.2 above. You can check your IPEDIT version by clicking the “alt+A”. If not, please move to the Aviosys official website download the latest version. IP Power 9658 Default Login / Password Default IP: 192.168.1.100...
  • Page 13 Notice : If can’t see the IP in the area of Local Devices of IPEDIT.exe. Please check the following situation 1. Boot up successfully: Please reboot the 9658 and check if there are 1 short beep after 10 seconds. This beep means the device boot up successfully. If not, the device may have issue.
  • Page 14 New Network Information 9658 IP Address: 192.168.1.26 Gateway Address: 192.168.1.1 Local Computer IP Address: 192.168.1.122 Sub Net mask: 255.255.255.0 Port: 80 2.) Press the “ Rescan ” button to see if changes have been made. 3.) Double click on the device in the local device section and an IE web browser with the device login will pop up.

  • Page 15: Internet Setup

    3.3.2 Internet Setup To connect the IP Power 9658 on Internet, there are two ways Setup Port Mapping / Port Forwarding in your router. Please check your Router owner’s manual. ⚫ 3.3.3 Using IP Service IP Service is a function which allows user to search for the device easily without having to remember lengthy complicated IP address.

  • Page 16: Mdns Connection

    4.) Find user device and double click on the screen and a web browser window will pop up connecting to user device. *User device must be Port Forwarded for the login screen to appear. EX: The 9658 device name as IP9658, and user can search the device easily : 5.) After user have connected to user device, type in the Login and Password for user device.
  • Page 17 Multiple IP9658 or others 9658 devices connect in the same PC. Find your device’s MAC address, which is located on the side of your device. (2-1) MAC example: 003258000520 (2-2) Open any web browser (recommend Chrome, Edge) (2-3) In the address bar, type “ ip9658_XX.local ”, where XX is the last two digits of your 9658 MAC address.

  • Page 18: Web Interface

    4. Web Interface Once the 9658 has been setup correctly, log into the device. The default Username and Password for the 9658 Username: admin Password: 12345678 The Control Console The right side Menu of the Web Interface control the functionality and setup settings of the IP Power 9658. The IP Power 9658 Console consists of four main sections which will be explained in details below.
  • Page 19 ◼ Timeout and Disconnect notice: *Timeout: If there are two users logged into your IP9658 at the same time, the first user who logs in will be forcibly logged out. *Disconnect Notice: If your 9658 connection suddenly lose the connection, 9658 webpage will display “Disconnect !!”...

  • Page 20: Top Column

    4.1 Top Column 4.1.1 Device name This section display the device name. You can change the device name here: Control → IO Control → Config → Device name, Change name “ IP9658 ” as “ Enjoy 9658 ” After apply the change, if your device name does not change, please click “ Refresh ” of the webpage to get the display update.

  • Page 21: Time

    4.1.2 Time In this section, it display Time at Year – Month – Date Hours : Minutes : Seconds . To setup the Time, Please go to “ Network → NTP ”, and press “Save” to save the new setting . Time - Manual setting or sync with NTP Server and then click “Apply”(2)

  • Page 22: Power Control

    4.2 Control The IO Control Section allows you to directly / automatically control the outlets of the 9658 as well as schedule Daily, Weekly, and Monthly power cycles. There are 3 sections: IO Control, Schedule, PING 4.2.1 Control There are 2 setting pages in this Section. One is “ Power Control ” and another one is “ Config ” A.
  • Page 23 1. Toggle switch: Each port ON or OFF directly by pressing the button. For example: The following pictures means that Power #1 & #2 is ON, Power #3 & # is OFF 2. Power Delay: It’s the delay function which works on the ON/Off buttons for the manual control at the interface of the webpage.
  • Page 24 For example: ( sec = seconds ) Original Outlet as “ OFF “ , select final status as “ OFF “ & fill 20 sec. After press “ Apply ” button, the outlet will turn ON for 20 seconds and then turn OFF. OFF →...
  • Page 25 B. IO Control config: Move to the IO control and click the Config. In this page, user can setup Name of each port and device, default power status, notification, WOL&SOL trigger relay and Current Limit(1~10)Amp. Name of Device and power: User can name each power by click the name above the power button.
  • Page 26 Current Limit(1~10)Amp: This feature allows setting an Amp limit, which will turn off the I/O control of the IP9658 device once the limit is reached. Before shutting down, a "Beep" sound will notify the user. If the number of notification is reached, the I/O control will be forcibly turned off. Notification times and Beep sound is available to settings.

  • Page 27: Schedule

    4.2.2 Schedule In this section, user can see the setting schedule list first up to 8 rules. To setup each schedule, please press “ Schedule Setting ”, then user can get the “ Schedule List “ page as following : Please click the “No.X“...
  • Page 28 The schedule allows you to control the power outlet or turn ON / OFF/ RESET at assigned time Adding a Scheduled Event 1. Select the Action Duration: There are 3 setting - Once, Every Day, Every Week Once: Example: Select the date 2024/8/16, time table: 8:00 a.m, task action: outlet 1 on...

  • Page 29: Every Week

    Every Week: Weekly Choice: You can choose single day, two days or more, even a whole week. Pic: Choose two days Pic: Choose every single day(a week). Example: Select two days (Monday and Wednesday), time table: 10:00 a.m, task action: outlet 1 ~4 on 9658 will trigger the outlet 1~4(on) at 10:00 a.m every Monday and Wednesday.
  • Page 30 2. Take example as “Once” settings, select a Specific Date Range where the device will repeat the desired actions during the time specified. 3. Select the Time table.
  • Page 31 4. Choose the Action: Enable power by clicking in the Task Action small black square, and select one from the power action of OFF/ON/Sys.Reboot/Nop/Opposite/Cycle on/Cycle off as you need. ⚫ ⚫ ⚫ Sys.Reboot: Reboot the device system. ⚫ Nop: Disable the task, no operation. ⚫...
  • Page 32 “Deactivated”(1) first, it will turn to “activated” mode Once the scheduler has been Set Up, click the then hit the “Group Apply”(2) button. If you don’t click the Deactivated first, only click the Save, it only save your setting in the schedule *Note: but won’t comply the setting.

  • Page 33: Ping

    4.2.3 Ping The Ping function allows the device to Ping an IP Address automatically to act as a watchdog to make sure the device getting Ping and working properly. Please Click the button to switch between “ Ping Setting “ & “ Ping List “ . User can hide the setting section by press “ Ping List ” There are 4 NO.X for Ping only, each rule can setup 1~4 outlets.
  • Page 34 These are the sections for each ping setting below: 1. Setting Rule Numbers: User can click to select different rules numbers in the right of “Ping list”, “ No.X ” as following pictures. 2. Global constant variables: Click the Global constant variables box first, then the Global constant variables will appear. ⚫...
  • Page 35 2-1 Input the IP Address ( ex: 122.116.123.138) or Host - web address (ex: www.google.com) user would like to Ping. 2-2 Ping Failure Threshold: Setup the times of Action after Ping Failure. Set number maximum is 99 counts. Click the icon first, then the Ping Failure Threshold will appear. 2-3 Delay: you can setting the delay time to turn on/off, cycle on/off the power.
  • Page 36 2-4 Job Action: Setting your ping action. Click Job Action(1) first, then Task option(2) will appears. 2-5 Job finished retry: (1) Stop ping: The device will stop the action after one times ping. (2) Continue X times. Depends on Global settings. (Retry job times). Recovery mode: This function prevents the device from causing damage to other outlets connected to it when unlimited ping attempts are set and the device still cannot connect to the IP.

  • Page 37: Network

    4.3 Network There are 2 sections in this port: Setup and NTP LAN Network Settings: The network status is connected by ether cable with RJ45 connector. There are 2 network connection way: Static IP / DHCP. *If you want to switch different connection between Static and DHCP, please move to setup setting → DHCP. 4.3.1 Setup Setup IP address, DNS, Port manually and enable DHCP, SNMP and TELNET.
  • Page 38 (1) Change date and time manually To change your date and time, click the calendar icon(1) first, then the calendar and time(2) will display. After setting your date and time, click the “Apply” to complete the setting. (2) SYNC with NTP-Server: Sync with the assigned sever, click the “SYNC with NTP-Server”, the time will sync with NTP immediately.

  • Page 39: System Setting

    4.4 System Setting 4.4.1 Management In this section there are 3 settings: Password, Import/Export Config file and Https Certificate. 1. Account management: (1-1) Passwordless authentication: You won’t need to enter 9658 through user and password when activated.
  • Page 40 (1-2) Change User Name: (1-3) Change Password: ◼ Please amend the password as number or English character from 1 to 14 characters. Do not use special symbol like “ ” ; ： ~ ! @ # $ % ^ & * ( ) This icon indicates that the password is hidden, if you click the icon two times, it will display the icon...

  • Page 41: E-Mail

    4.4.2 E-mail ⚫ Email Setting: User can get e-mail advice as one of the following situation happen: - Receive E-mail with IP information & MAC Address as 9658 device boot up. - Receive E-mail as ON/OFF status change in each output. Forgot Password Function: 9658 will provide a temporary password through email.
  • Page 42 ◼ Forgot password function: If you already complete setting your mail config and click the “Apply” (config pic), the forgot password function will activate automatically. config pic: To see how the forgot password works, please click log out. You will see the login webpage will appears the “Forgot Password”.(Pic 1) Click the “Forgot Password”, it will appears the “e-Mail Password verification”.(Pic 2) Enter the password verification you set in the “Mail config ”.
  • Page 43 When you go to your email webpage, you will receive an email from IP9658. It provides your username and temporary password. The password is generated by 9658 for you to log in. After you login, 9658 webpage will directly move to Account management, and your old password appears.

  • Page 44: Ipservice

    4.4.3 IPService In this section, user can setup: IP Server & CNT ( Cross Network Technology ) , CNT ( MQTT ) A. IP Service & CNT Setting : The IP SERVICE allow 9658 to be accessed easily on the internet by our IP Power Center or IP EDIT.
  • Page 45 Please refer page #14 for the function of IP Server B. CNT ( MQTT) – For developing only. 9658 supports MQTT fucniton. Please contact with your distributor for the details if you would like to develop own system. - 45 -...

  • Page 46: Eventlog

    4.4.4 Eventlog In this section, user can get the 9658 system operation information and send the information to assign Server IP address ( not support name ). The system information will be deleted after 9658 device power reboot. Log file: 9658 System log support to export the file, and the clearSyslog function. Power, System section: Click each of them will display their own graph.
  • Page 47 Power section: It will display a graph of your power on/off history. System Section: It will display the 9658 device system working log history. Not including other history(e.g. power on/off) - 47 -...

  • Page 48: Firmware

    There are four sections: OTA, Local upgrade, Factory reset, Reboot. (1) OTA: (1-1) OTA IP Power update: Update by the AVIOSYS official server, when the update news released, you can click the “Firmware Update” to update without any procedure. *Note: OTA requires the network to update the firmware, please make sure your 9658 is connect with the internet if you use choose the OTA to update.
  • Page 49 The firmware update function only support in LAN connection. Before update, please DO READ THE HI-LITE MESSAGE BLOW: It takes about 1 minute to upload upgrade flash and be patient please. Caution! A corrupted image will hang up the system. To update the 9658, please follow the instruction below to prevent anything happens like update incomplete or hardware disable which may be caused by wrongdoing of updating: 1) Turn off all chat programs including ( Skype, FB.

  • Page 50: Other Ways To Control

    5. Other ways to control Besides web page control, there are several ways to control the outlets : by HTTPS/CGI command or by Telnet. 9658 also support SNMP (MIB). Please check page #37 to check and enable the function. 5.1 CGI HTTP Commands CGI Commands allow you to easily integrate the 9658 with other systems and programs.

  • Page 51: Telnet Control

    5.2 Telnet Control Please enable the telnet function in “Network “ → “ Setup “ Or Check page #37 to check and enable the function. - 51 -...
  • Page 52 6. FAQ : Q1: Why can't I see the 9658`s IP address in IPEDIT.exe ? Ans.: Please check the PC you use is under same LAN/ network / segment as 9658. Please turn off some Anti-Virus / online chatting software. If there are morn than 1 network card, include dynamic network card, please disable one and make sure the one you selected is under the same segment with IP9658.
