I/O CONTROLLER to Ethernet
Model : IOW-924
Your purchase of this
I/O & MRC meter RS232 interface
to Ethernet CONVERTER marks a
step forward for you
into the field of
precision measurement.
Although this Meter is a
complex and delicate
instrument, its durable
structure will allow
many years of use if
proper operating
techniques are
developed. Please read
the following
instructions carefully
and always keep this
manual within easy
reach.
OPERATION MANUAL
PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION
3, Hagavish st. Israel 58817 Tel: 972 3 5595252, Fax: 972 3 5594529
mrc@mrclab.com
MRC.11.17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IOW-924 and is the answer not in the manual?

Questions and answers

Related Manuals for MRC IOW-924

Summary of Contents for MRC IOW-924

  • Page 1 I/O CONTROLLER to Ethernet Model : IOW-924 Your purchase of this I/O & MRC meter RS232 interface to Ethernet CONVERTER marks a step forward for you into the field of precision measurement. Although this Meter is a complex and delicate...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. FEATURES......................... 2. SPECIFICATIONS...................... 3. FRONT PANEL DESCRIPTION................. 4. MEASURING PROCEDURE................4-1.The initial startup screen ..................4-2.Measuring and setting screens ................4-3.The summary description of keyboard ............... 4-4.Setting Description ....................4-5.Set value storage ....................4-6.Ethernet connection ................... 4-7.Reply factory setting....................

  • Page 3: Features

    1. FEATURES １ . Features: Automatically switch I / O control functions or MRC meter RS232 transmission function. * I/O terminal: 1.DC 9V power input. 2.DC 9V power output(power supply for the connecting RS232 meter). 3.2 switch inputs. 4.2 relay outputs.

  • Page 4: Specifications

    Accessories * Instruction manual..............included * Hanging unit ( with sticker )..........* AC to DC 9V power adapter............. * Full line MRC RS232 meters. Optional Accessories * Data interface cable, UPCB-03. * Power interface cable, PWCB-06.

  • Page 5: Front Panel Description

    3. FRONT PANEL DESCRIPTION Fig. 1 3-1 DC 9V Power adapter input socket 3-2 DC 9V output socket 3-3 Isolate input socket 3-4 Input Terminals 3-5 Output Terminals 3-6 Display 3-7 SETUP/ENTER KEY 3-13 System reset button 3-8 EXIT( ) key button 3-14 Network socket (RJ45) 3-15 Hanging holes ▲...

  • Page 6: Measuring Procedure

    4. MEASURING PROCEDURE 4-1.The initial startup screen SCREEN4-1-1 SCREEN4-1-2 4-2.Measuring and setting screens: 1.Measurement screen: SCREEN4-2-1 SCREEN4-2-2 2.Setting screen: SCREEN4-2-3...

  • Page 7: 4-3.The Summary Description Of Keyboard

    4-3.The summary description of keyboard: 1.SETUP(Enter) KEY: Setting screen into the select key. 2.In the setting mode: 2-1.Press to select the field in the upper and lower beating. ▲ ▼ 2-2. > 2 SEC.: The selected field will rapidly beating. ▲...

  • Page 8: 4-5.Set Value Storage

    SCREEN4-2-2, after about 25 SEC later. would return SCREEN4-2-1. 4-8.IO Control Function: 1.First, install MRC dedicated IO APP software: 1-1.The use of smart phones Android or iOS system software download MRC IO App (SCREEN4-8-1).
  • Page 9 2.The machine will boot into the measuring screen (SCREEN4-2-1): 2-1.Set parameters determine the following (SCREEN4-2-3): 2-1-1.IP: 192.168.0.254 2-1-2.Port: 200 2-1-3.Gateway: 192.168.0.1 2-1-2.APP Password: AA0000 2-2.Start smart phone, open the IO App software, for native control. 2-3.IO App software-related settings section: 2-3-1.At this show SCREEN 4-8-3, select Step2 tool button then into the SCREEN4-8-4.
  • Page 10 long press> 2 SEC. By OFF to ON (eg SCREEN4-8-6 ), while the unit's OUTPUT DISPLAY Its O1 or O2 will be blinking (eg SCREEN4-8-10). 2) TIME RELAY1 OR RELAY2 ON/OFF CONTROL: When RELAY 1 or RELAY 2 is OFF (SCREEN4-8-3 of STEP6), CONTROL MODE to MANUAL state (SCREEN4-8-3 of STEP7).
  • Page 11 4) INPUT1 OR INPUT2 PULSE CLEAR: According SCREEN 4-8-8, press PULSE CLEAR BUTTON (eg SCREEN4-8-3 the STEP10), The screen becomes SCREEN4-8-10 state, and this machine screen INPUT1 or INPUT2 becomes SCREEN4-8-11. SCREEN4-8-3 SCREEN4-8-4 SCREEN4-8-5 SCREEN4-8-6 SCREEN4-8-7 SCREEN4-8-8...

  • Page 12: 4-9.Rs232 Transmission Function

    SCREEN4-8-13 SCREEN4-8-13 4-9.RS232 transmission function: 1.First, install MRC dedicated APP software: 1-1.The use of smart phone Andriod or iOS system software download MRC MeterApp (SCREEN4-8-1), Andriod Password: Az6210 ,iOS Password: aZ6210. 1-2.After the download is complete, then install it. SCREEN4-9-1...
  • Page 13 2.When using MRC meter can be RS232 output, insert IOW-924E RS232 INPUT (Fig.3-3), this time the machine will automatically become RS232 transmission function by the IO control function. 3.Open Meter App software (such as SCREEN4-9-22): 3-3-1. In SCREEN 4-9-2 select Step 1 (Meter 1).
  • Page 14 3-3-9.Manaul Log: Each time you press the tool button, then record sum. * Record file format is xml. 3-3-10.View Log: The recorded data can be seen directly in the smart phone (eg SCREEN4-9-7). 4.When IOW-924E RS232 INPUT No signal detected, approximately 20 seconds will automatically cut the IO control functions.

  • Page 15: 4-10.Direct Connection Network Mode (Internal Network)

    4-10.Direct connection network mode (internal network): 1.Network schematic diagram: I n t e r n e t M o d e m I P R o u t e r L A N P O R T I O W - 9 2 4 E 2.Related parameters: 2-1.IP: 192.168.0.254 2-2.Port: 200...

  • Page 16: 4-13.The Unit Via A Wireless Bridge Network Connection

    3.into the IP Router do parameter setting, set the contents of the red box. 4-13.the unit via a wireless bridge network connection (external network floating IP): 1.Network schematic diagram: U R L f o r w a r d i n g I n t e r n e t M o d e m I P R o u t e r...
  • Page 17 3.into the IP Router do parameter setting, set the contents of the red box . 4.Go www.dlinkddns.com site for a free transfer, will be transferred to the name of the applied input address to the IP Router.

  • Page 18: Screen4

    5.When performing IO APP or Meter App,Enter the desired parameters shall utilize IP Tools software to enter after that.As SCREEN4-8-4, SCREEN4-8-5 or SCREEN4-9-4.
