Installation Notice
Quick Installation Guide
Package Contents
Quick Installation Guide
Model: R2 / R4
Model: R2
IP Camera
Quick Installation Guide
CD-ROM
Warranty Card
Security Warning
Suggest you to change the password of your camera
Model: R2 / R4
Model: R2
regularly, the password should be the combination of
numbers,letters and special characters.
To make sure your camera is safe and you get the better
product experience ,we suggest you to update your camera
to the latest rmware every three months.
Please take good care of your camera username and
V1.0
password, do not let other person know these information.
2
Physical Description
Front panel
Lens
Infrared LED
Wi-Fi Antenna
Power Adapter
Micro SD Card Slot
WPS/Reset
Mounting Bracket (R2) Mounting Bracket (R4)
Microphone
Rear panel
Speaker
Network light
Antenna
Power
LAN
Power light
3
4
Download APP
Add IP Camera
To install the Foscam APP on your smartphone, you can
There are two ways (Wired connection and Wireless
choose either of the following methods:
connection ) to add IP camera via Foscam APP. You can
choose either of the following way:
Scan QR code
Note:
If you have a QR Code APP on your phone, scan the
For R4, In order to watch smoother video, we recommend that
code below.
you use wired connection.
4.1
Wired Connection
Foscam
Download from App store
You can simply go to the App Store or Google Play Store
and search for the term "Foscam". Find the APP that
appears with the same icon as shown above, and
download it to your device.
1.
Connect the power adapter to the camera and wait
a moment. Then the camera will play a sound
Before you continue, please note:
"Hello, Foscam" .
2.
Connect your camera with router by Ethernet cable, then
Make sure your wireless router is enabled DHCP feature,
the camera will play a sound " Wired connection
and connected to internet.
succeed".
Make sure your smartphone is connected to your
Make sure your smartphone is connected to your wireless
3.
wireless router and located near the camera.
router.
4.2
4.
Run the Foscam APP
on your smartphone, register
Wireless Connection
an Foscam Cloud account then log in. Please follow the
below steps to add your camera.
My Cameras
Setup Wizard
Scan
Add New Camera
Please scan the QR code on
Scan the
Tap here
your camera to add.
Tap here
Please put the QR code within the frame. Put the
barcode outside the frame to avoid interference.
QR code
Note:
Do not connect the camera with router via Ethernet cable.
Tap '+' to add new camera
Tap to scan QR Code
1.
Install wireless antenna and position upright.
Album
2.
Connect the power adapter to the camera and wait a
moment. Then the camera will play a sound "Hello,
Foscam" .
3.
Make sure your smartphone is connected to your wireless
router.
Setup Wizard
4.
Run the Foscam APP
an Foscam Cloud account then log in. The camera will
√
Connection
Connection succeeded!
succeeded!
play the warming tone "Ready for WiFi con guration",
Tap the camera in the list to
watch live video.
轻触扫描二维码
then you can follow the below steps to add your camera.
WiFi
WPS
on your smartphone, register
