FTE Maximal HCA ZM 20-65 User Manual

Chapter 1. Installation.

1.1. Safety measures

1.- Never place the equipment next to hot sources.
2.- Never undergo the equipment to temperatures that exceed the level of operation of the device.
3.- Do not expose the equipment to dripping or splashing.
4.- Do not place objects filled with liquids, such as vases, on the equipment.
5.- Respect ventilation slots of this equipment. Avoid covering them with any object.
6.- Keep clean and without obstacles a minimum radius of 40 cm around this equipment.
7.- Avoid locations with possibilities of spilling liquids on the inside of the device, and with important changes of
temperature.
8.- Never open the equipment yourself due to electric risk. In case of problems, go always to qualified technicians..
9.- Never, under no circumstances, open the equipment connected to the electrical net.
10.- During the handling it is better to disconnect the equipment of the electrical net.
11.- Respect the electricity security rules during the assembling. Use materials that obey the current law.
12.- The connecting plug must be accessible in a fast and simple way to have a fast disconnection.
13.- Never touch the plug with wet hands. Also, disconnect always the device before handling the connections..
14.- Never put any heavy object over the device, as it could get damaged.
15.- If the equipment is going to remain some time without use, it is recommendable to disconnect it from the electrical
net.
16.- The repairmen and the maintenance of the equipment must be done by TV and radio specialist technicians.

1.2. Box Content

HCA ZM 20-XX / HCA ZM 30-XX

1.3. Description and Connections

This family of broadband amplifiers has a configurable return path that can be active or passive. The difference between
amplifiers is that HCA ZM XX-30 models have a 5-30 MHz return path and HCA ZM XX-65 models have a 5-65 MHz
one.
These amplifiers have aluminium housing with a removable cover that allows the installer to configure the amplifier
according to the needs of the installation.
User's Guide · HCA ZM 20-XX / HCA ZM 30-XX
- 1 -
User's Guide
HCA ZM 20-XX / HCA ZM 30-XX Version_en_1.2 FTE maximal
