VTech VC7002A User Manual page 2

Mount the sensor unit
Without spacer
Mount with tape
1. Attach mounting tape B onto the
rectangular area at the rear side of the
back cover
2. Stick the sensor unit onto the frame.
With spacer
Mount spacer with tape
1. Attach mounting tape A onto the
rectangular area at the rear side of the
spacer.
2. Stick the spacer onto the frame.
-OR-
Mount spacer with screws
1. Use a pencil to mark two holes on the
desired location on the frame, with the
aid of the two holes on the spacer of the
sensor unit. Then, remove the spacer and
drill two holes into the frame.
2. Align the holes on the spacer with the
holes on the frame. Tighten the large
screws into the holes to secure the spacer
onto the frame.
Mount sensor unit onto spacer
3. Press the latch button on the sensor unit to
open the battery compartment case from
the back cover.
4. Align the holes on the battery
compartment back cover with the holes on
the mounted spacer.
5. Tighten the small screws into the holes to
secure the back cover of the sensor onto
the mounted spacer.
6. Push the battery compartment case back
onto the mounted spacer until it securely
clicks into place.
Disclaimer
This product is not designed for security purposes.
When properly installed and maintained, this
product may in some cases reduce the risk of
burglary, fire, robbery or other events occurring
without providing an alarm. VTech is not responsible
for losses, injury, or damage resulting from the use
of this product.
General product care
Taking care of your sensor
Your sensor contains sophisticated electronic
parts, so it must be treated with care.
Avoid rough treatment
Place the sensor down gently. Save the original
packing materials to protect your sensor if you
B B
ever need to ship it.
Avoid water
Your sensor can be damaged if it gets wet. Do
not use the sensor outdoors in the rain, or handle
it with wet hands. Do not install the sensor near a
sink, bathtub or shower.
Electrical storms
Electrical storms can sometimes cause power
surges harmful to electronic equipment. For your
own safety, take caution when using electrical
appliances during storms.
Cleaning your sensor
A Your sensor has a durable plastic casing that
should retain its luster for many years. Clean it
only with a dry non-abrasive cloth. Do not use
dampened cloth or cleaning solvents of any kind.
Storage
When you are not going to use the sensor for
some time, remove the battery from the sensor.
Store the sensor in a cool and dry place.
Frequently asked questions
Below are the questions most frequently asked
about the sensor.
The sensor Make sure two AAA alkaline
does not batteries are installed.
work at all.
The sensor may be deregistered
from the telephone base. Register
it back to your telephone base.
The sensor may be out of range.
Move the sensor closer to your
telephone base.
Battery
Important safety instructions
• CAUTION: Use only the batteries indicated in
this manual. There may be a risk of explosion if
When using your equipment, basic safety
a wrong type of battery is used for the sensor unit.
precautions should always be followed to reduce
• Do not dispose of the battery in a fire. Check
the risk of fire, electric shock and injury, including
with local waste management codes for special
the following:
disposal instructions.
1. Adult setup is required.
• Do not open or mutilate the battery. Released
2. Do not use this product near water. For
electrolyte is corrosive and may cause burns or
example, do not use it next to a bath tub, wash
injury to the eyes or skin. The electrolyte may be
bowl, kitchen sink, laundry tub or swimming
toxic if swallowed.
pool, or in a wet basement or shower.
• Exercise care in handling batteries in order not to
3. Do not place this product on an unstable table,
create a short circuit with conductive materials.
shelf, stand or other unstable surfaces.
4. This product should not be placed in any area
where proper ventilation is not provided. Slots
and openings in the back or bottom of this
product are provided for ventilation. To protect
them from overheating, these openings must
not be blocked by placing the product on a soft
surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator
or heat register.
5. Never push objects of any kind into this product
through the slots because they may touch
dangerous voltage points or create a short circuit.
Never spill liquid of any kind on the product.
6. To reduce the risk of electric shock, do not
disassemble this product, but take it to an
authorized service facility. Opening or removing
parts of the product other than specified
access doors may expose you to dangerous
voltages or other risks. Incorrect reassembling
can cause electric shock when the product is
subsequently used.
7. Periodically examine all components for
damage.
8. Children should be supervised to ensure that
they do not play with the product.
9. The product is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance by
a person responsible for their safety.
SAVE THESE INSTRUCTIONS
VTECH TELECOMMUNICATIONS LTD.
A member of THE VTECH GROUP OF
COMPANIES.
© 2016 VTech Telecommunications Ltd.
All Rights Reserved. V1.0. 04/16
Technical specifications
Transmit frequency 1881.792 MHz - 1897.344
MHz
Channels 10
Sensor operating 0°F (-18°C) to 130°F (55°C)
temperature
Nominal effective Actual operating range
range may vary according to
environment conditions at
the time of use.
Power requirements 2 x AAA alkaline batteries
