CTC Union FRM220-40G-2Q User Manual

CTC Union Technologies Co.,Ltd.
Far Eastern Vienna Technology Center
(Neihu Technology Park)
8F, No. 60, Zhouzi St., Neihu, Taipei 114,
Taiwan
T +886-2-26591021
F +886-2-26590237
E sales@ctcu.com
marketing@ctcu.com
H www.ctcu.com
2018 CTC Union Technologies Co., LTD.
All trademarks are the property of their respective owners.
Technical information in this document is subject to change without notice.
User Guide
40G Transponder
FRM220-40G-2Q
Table of Contents
Introduction/Features
Specifications
Management Features
Chassis Installation
LED Indicators
Console Management
Fiber Configuration
Loopback Testing (LBT) Function
Version 1.0 August 2018
w w w . C T C U . c o m
------- 1
Panel ------- 2
------- 3
------- 3
------- 4
QSFP+ Unit ------- 4
DIP Settings ------- 5
------- 6
------- 7
------- 9
------- 12
Upgrading ------- 13
Introduction
The FRM220-40G-2Q is a 40G QSFP+ transponder that aggregates
10Gbps services up to 40Gbps and extends transmission distance. To meet
the growing needs for more bandwidth for data centers and enterprises,
FRM220-40G-2Q can also transport various wavelengths in the optical
network and can receive, amplify and re-transmit the signal for continuous
transmission. The emergence of high-end servers and Ethernet Switches
with 40G Ethernet interfaces also increases the need for media conversion
(multi-mode to single-mode) and link range extension.
The FRM220-40G-2Q is hot-swappable card with two QSFP+ slots for
40G QSFP+ transceivers. All slots support plug-and-play. When the
FRM220-40G-2Q card is placed in the Chassis rack with SNMP
management, the network personnel can view the converter card's status,
type, version, fiber link status. The card can be configured to enable or
disable the port, reset the port, provide diagnostic loopback and activate link
fault pass-through function.
Features
Network management via FRM220 chassis
Supports 40G repeater mode or Quad 10G optical multiplexer mode
40G link interface -- Ethernet/IEEE: 802.3ba 40GbE-SR4/LR4/ER4
40G multi-link (fiber) interfaces -- Ethernet/IEEE: 802.3ba XLAUI and
OIF: CEI-11G
QSFP+ slots for flexibility and scalability
Supports hot-swapping (module and interfaces)
Supports jumbo frame
Supports DMI function for QSFP+ fiber module
Supports loopback test function
Supports Link Fault Pass-Through function
3R function (Re-generator, Re-shaper, Re-timer)
RoHS compliant and Lead-Free
