Maxi Walk-Thru Gate
with Pet Door
MODEL NO: 1210
Owner's Manual
Carlson Pet Products, Inc.
3200 Corporate Center Drive, Suite 105
Burnsville, MN 55306-9804,USA
Phone: 952-435-1084
Made in China
Advertisement
Related Manuals for Carlson 1210
Summary of Contents for Carlson 1210
- Page 1 149mm Maxi Walk-Thru Gate with Pet Door MODEL NO: 1210 Owner’s Manual READ ALL INSTRUCTIONS BEFORE ASSEMBLY AND USE OF GATE. KEEP INSTRUCTIONS FOR FUTURE USE. www.carlsonpetproducts.com Carlson Pet Products, Inc. 3200 Corporate Center Drive, Suite 105 Burnsville, MN 55306-9804,USA...
- Page 2 按排版格式此处为空面！！！...
-
Page 3: Assembly And Installation Instructions
NOTE: If wall mounting your gate to a surface other than drywall or wood, please contact a professional about installation. Contact Carlson for questions and replacement parts. For questions about the use of your pet gate, call our customer care line 952-435-1084. - Page 4 Check to make sure you have all of the parts shown: Maxi Gate Main Panel Maxi Gate Extension Panel 4 Maxi Mounting Brackets 4 Maxi Threaded Rods Stabilizing Foot 8 - 1” Screws ( requires a Phillips/crosshead screwdriver 4 Double Ended Screws ( requires a Phillips/crosshead screwdriver Paper Wall Mounting Template...
- Page 5 Assembling and Installing Your Gate: Step 1. Determine the width of your doorway or opening. For openings between 34” and 39”: Remove and discard the protective end screws located at points X and Y in Diagram A, then skip to Step 3. For openings between 49”...
- Page 6 Step 3. Screw in the 4 Threaded Rods into the 4 corners of the assembled gate. The Threaded Rods do not need to be fully screwed in, nal adjustments will be made before completing installation. Diagram B Step 4. Use the Paper Wall Mounting Template to help you mark the exact locations to attache the Maxi Mounting Brackets To use the Paper Wall Mounting Template, place it against the wall with the bottom edge of the template touching the oor.
- Page 7 Step 5. Use the 8 included 1” Screws to attach the Maxi Mounting Brackets to the wall at the locations you marked in Step 4. NOTE: The Mounting Brackets must be orientated so that the Release Tabs are towards the top. See Diagram D Release Tabs Diagram D Step 6.
- Page 8 Step 7. Connect the assembled gate to the wall by inserting the at ends of the Threaded Rods into the semi-circle slot at the bottom of each Maxi Mounting Brackets. Adjust the length of the threaded rods appropriately to allow for installation. After proper insertion, the Threaded Rods will lock in place.
- Page 9 Carlson Pet Products will replace or repair it at Carlson’s option. PROOF OF PURCHASE REQUIRED.
- Page 10 Replacement Parts Available In the event of any damage or breakage, the following replacement parts are available for order by contacting Carlson Pet Products Customer Service. Double Ended Screw (#10046) 1” Wall Mounting Screw (#10001) Maxi Mounting Bracket (#13047) Maxi Threaded Rods...
- Page 11 Carlson Pet Products,Inc 3200 Corporate Center Drive, Suite 105 Burnsville, MN 55306-9804,USA Phone:952-435-1084 01/20/2014_EV...
