- Page 1 BITMAIN S7 Server Manual...
-
Page 2: Table Of Contents
S7 Server Manual Last updated: 2/1/2016 Page 2 of 12 Contents Overview ........................... 3 Features ............................. 4 Power Supply..........................4 Connect to server ........................6 Server Configuration ........................8 Pool Setting ........................8 Frequency Modification ....................8 Server Status ..........................9 System Configuration and status .................... -
Page 3: Overview
Page 3 of 12 1 Overview The S7 Server with is Bitmain’s newest iteration, using the new state of the art BM1385 chip with full-customs made, powered by ultra-low power 28nm technology. It’s with several different hash rate and the final one is 4.73th/s. S7s are tested and configured prior to shipping to make it easier for customers to set up. -
Page 4: Features
S7 Server Manual Last updated: 2/1/2016 Page 4 of 12 2 Features Ideal Hash Rate (GH/s) 4.73 GH/s Default chip clock (M) Input Voltage (V) 11.6~13.00 Estimate power on wall (W) -- assume with 1293W + 10% APW3, 93% efficiency, 25℃ ambient temp) Estimate efficiency on wall (J/GH) 0.25J/GH + 10% Dimensions (mm) - Page 5 S7 Server Manual Last updated: 2/1/2016 Page 5 of 12 Page 5 / 12...
-
Page 6: Connect To Server
S7 Server Manual Last updated: 2/1/2016 Page 6 of 12 4 Connect to Server Step 1. The default DHCP network protocol distributes IP addresses automatically. Please download IPReporter.zip, then please follow below steps to find out the IP of the server. - Page 7 S7 Server Manual Last updated: 2/1/2016 Page 7 of 12 Step 2. Enter the IP address provided into your WEB browser and proceed to login using ‘root’ for both the username and password. In the ‘Network’ section, you can assign a ‘Static’ IP address if you like. Click ‘Save&Apply’ after modifying it.
-
Page 8: Server Configuration
S7 Server Manual Last updated: 2/1/2016 Page 8 of 12 5 Server Configuration 5.1 Pool Setting You can configure your server through ‘ Configuration->General Settings‘. Pool URL- Enter the URL of your desired pool in this column. Worker- This is your worker ID on the selected pool. Password- This is the password for your selected worker. -
Page 9: Server Status
S7 Server Manual Last updated: 2/1/2016 Page 9 of 12 6 Server Status You can check the operating status of your server on the page marked below. ASIC#: Number of chips detected in the chain Frequency: ASIC frequency setting Temp: Temperature, centigrade ASIC status: o stands for OK, x stands for error. -
Page 10: Password Modification
S7 Server Manual Last updated: 2/1/2016 Page 10 of 12 ‘Keep setting’ is chosen by default and should be enabled if you want to keep your current settings. You should deselect this option if you are trying to return the server to default settings. -
Page 11: Software Version Checking
S7 Server Manual Last updated: 2/1/2016 Page 11 of 12 7.3 Software Version Checking You can check which version of the software you are currently running on the ‘System->Overview’ page. ‘File System version’ displays the date of the firmware your server use. - Page 12 S7 Server Manual Last updated: 2/1/2016 Page 12 of 12 Page 12 / 12...
