Summary of Contents for BITMAIN AntMiner S2
- Page 1 BITMAIN AntMiner S2 Manual...
-
Page 2: Table Of Contents
AntMiner Manual Last updated: 4/14/2014 Page 2 of 9 Contents Overview ........................... 3 Connect to Miner ........................4 Pool Setting ..........................5 Miner Status ..........................6 System Configuration and status ....................7 System Upgrading ......................7 Password Modification ....................8 Software Version Checking .................... -
Page 3: Overview
Page 3 of 9 1 Overview AntMiner S2 is a chassis style 1TH/s bitcoin miner with PSU. It has been assembled before Fab out. 1000W PSU: when you set up AntMiner S2, only need to connect to AC 220V/50Hz or 110V/60Hz. -
Page 4: Connect To Miner
AntMiner Manual Last updated: 4/14/2014 Page 4 of 9 2 Connect to Miner Step 1. Manually set up your PC’s IP address in the network segment same as the miner’s IP address. Default IP address of S2 is 192.168.1.99 by default, set up PC’s address to 192.168.1.x. Step 2. -
Page 5: Pool Setting
AntMiner Manual Last updated: 4/14/2014 Page 5 of 9 3 Pool Setting Through ‘Status->Miner Configuration ‘, you will be able to configure your miner. Pool URL-In this field you should enter the URL of your desired pool. Worker- This is your worker ID on the selected pool. Password- This is the password for your selected worker. -
Page 6: Miner Status
AntMiner Manual Last updated: 4/14/2014 Page 6 of 9 4 Miner Status 4.1 Miner Status web page Through ‘Miner Status‘, you will be able to check your miner running status. ASIC#: ASIC number in the chain Frequency: ASIC setting frequency Temp: Temperature, centigrade ASIC status: o stands for OK, x stands for error. -
Page 7: System Configuration And Status
AntMiner Manual Last updated: 4/14/2014 Page 7 of 9 Hash rate: 1255.82 GH/s, average speed every one minute. Temperature: the maximum value among all collected data. 4.3 LED and beep 4.3.1 When the miner is running well, green LED flashing with 1 second interval. If network is off for more than one minute, Green LED will be off and beeper rings. -
Page 8: Password Modification
AntMiner Manual Last updated: 4/14/2014 Page 8 of 9 Choose ‘Reboot’ button, Miner will restart and run the new system. Choose ‘Go Back’, Miner will continue running the old system, will run new system when power on next time. 5.2 Password Modification Through ‘System->Administration’, you will be able to modify AntMiner login password, and choose ‘Save’... -
Page 9: Restore Initial Setting
AntMiner Manual Last updated: 4/14/2014 Page 9 of 9 5.4 Restore Initial Setting Press the ‘Reset’ button on the left bottom of LCD screen and hold on for 3 seconds, red led flashing every one second/ 1S. Release ‘Reset’ button, Miner will restore the initial setting and restart automatically.
