REVERSING DOOR THE DOOR SWING
Rehang Freezer Door
* Lower bottom socket of freezer door onto
bottom hinge bracket. Be sure
washer is in place.
* Tilt door toward cabinet and gently push
door under center hinge bracket and
align with the hole in the center
hinge bracket.
* Reinstall hinge pin with a 7/32" socket and
ratchet so it extends through a hole
in center hinge bracket and into
socket on top of freezer door.
Rehang Refrigerator Door
On Models with a full-width freezer door
handle:
* Lower bottom socket of the refrigerator
door onto center hinge pin. Be sure
washer is in place.
* Tilt door toward cabinet, lifting the top hinge
so the pin fits into the socket on top
of the door.
* Tighten the top hinge screws after support
ing the door on the handle side and
ensuring the gap between the doors
is even all across the front.
Normal Operating Sounds.
1. Evaporator fan: Air being forced through the cabinet.
2. Evaporator: Flow of refrigerant may creat a boiling or
gurgling sound.
3. Defrost heater: During defrost cycles, water dripping
on the heater may cause a hissing or sizzling sound.
After defrosting, a popping sound may occur and the
evaporator may create a boiling or gurgling sound.
4. Cold Control and Defrost Timer: Snapping sound or
timer sound like a clock.
5. Water pan: Water may be heard running into the drain
pan during the defrost cycle.
6. Compressor: High pitched hum, or pulsating sound.
7. Condenser Fan: Air forced over condenser by fan
PLASTIC
WASHER
FREEZER
DOOR
.
18
HINGE
PIN
CENTER
HINGE
BRACKET
