GE PROFILE TCX18I Technical Service Manual page 18

Transfer Door Stops
One each door remove the metal stop. Use the
center hinge pin as a guide to align the door stop on
the opposite side, after reversing the handles.
REVERSING DOOR HANDLES
Transfer the Refrigerator Door Handle to
the Right
* Remove the four handle mounting screws.
* Using a putty knife, remove the four screw
hole plug buttons from the right side
of the door.
* Reinstall the plug buttons on the left side of
the door.
* Align the handle over the holes in the right
side of the door and install the four mounting
screws.
* At the top of the door, remove the plug
button using a putty knife and
reinstall it in the top right hand side
hole.
NOTE: Make sure the door stop on the bottom of the
door has been transferred to the left side of the door
as explained.
Prepare the Freezer Handle for Door
Swing Change
On Models with a full-width freezer door
handle:
* Simply remove the plug button from the top
left corner and transfer it to the top right corner of the
freezer door.
NOTE: make sure the door stop on the bottom of the
door has been transferred to the left side of the door
as explained above.
On Models with a partial-width freezer door
handle:
* Remove the plug button and screw from
the top right hand side of the door.
Remove the two screws from the
handle.
* Install the machine screw in the hole that is
closest t the center of the door.
Reinstall the screw and plug button
to the top left hand side of the door.
DOOR STOP
WASHER
LEFT SIDE
HANDLE
MOUNTING
SCREWS
HANDLE
PLUG
BUTTON
PLUG
BUTTON
17
WASHER
RIGHT SIDE
FRESH PLUG
FOOD BUTTON
DOOR
TAPPING
SCREW
MACHINE
SCREW
