Do a quick measurement

To do a quick measurement without the smartphone application connected,
press the On/Off button briefly. Results are shown on the wire pair status
LEDs.
Status Possibe Faults
Red Voltage > 10V present on the pair
Green Pair termination within tolerance, pair connected to another Ethernet
port
Pair open, unconnected
Yellow
Magenta
Pair has termination error (bad cabling, non-Ethernet port, 10/100
spare)
Ethernet link established on port
Blue
Ethernet link established and DHCP address obtained on port
White
