(4) Ethernet wire pair status LEDs

After a 'quick measurement' each of the LEDs show the state of a wire pair in the cable On
the left is Pair 1, on the right is Pair 4.Colors indicating the states:
Status Result
Red
Voltage > 10V present on the pair
Green Pair termination within tolerance, pair connected to another Ethernet port
Yellow
Pair open, unconnected
Magenta
Pair has termination error (bad cabling, non-Ethernet port, 10/100 spare)
Blue Ethernet link established on port
Ethernet link established and DHCP address obtained on port
White

(5) Ethernet port

Plug in the Ethernet cable that you'd like to test here

Reset the device

Should the device show symptoms of software failure; not going through the measurement
cycle, not charging or communicating with the smartphone application. Press and hold the
power button (1) for 10 seconds and then connect the USB cable to reset the device.
