THE APP - TEST VIEW

Wiremap

The wiremap test determines (by transmitting signals through each wire) if a
pin on a connector is connected to the correct pin at the other end.
Status Possibe Faults
Miswired
Damaged connector / Cuts or breaks in cable / Wires connected to
wrong pins at connector or punch block
Short Circuit
Improper connector termination / Damaged Connector / Conductive
material stuck between pins at a connection / Damage to cable
OK
There's a connection to the wiremap-Adapter
The graphical wiring diagram shows the status of each individual wire: the
corresponding connected pin is shown on the right side. In case of short
circuits between the wires, these are shown with a red vertical connection,
opens are shown in the middle as a break in the line.
The pair numberings and colors are based on the TIA colour scheme
selected in the tools -> settings menu.
To get a valid result, you need the have the Pockethernet terminator adapter
with the "Wiremap" side attached to the other end of the cable. Pockethernet
is only compatible with the wiremap adapter that came with Pockethernet.
