Erreka MAGIC Quick Installation And Programming Manual

MAGIC
Quick installation and programming guide
This quick guide is a summary of the complete installation manual. The manual contains safety warnings and
other explanations which must be taken into account. The installation manual can be downloaded by going
WARNING
to the "Downloads" section of Erreka website:
http://www.erreka-automation.com
*
2
4 x 1mm
(max. 20m)
2
Rx: 4 x 0,5mm /
2
Tx: 2 x 0,5mm
(max. 30m)
TA
VERY IMPORTANT:
The TC closing limit switch and the TA
opening limit switches must be installed
in all cases.
Electrical wiring
A: Main power supply
B: LUMI flashing light
C: Photocells (Rx/Tx)
D: Pushbutton/key switch
E: Operator *:
2
motor: 4x1mm
2
brake: 2x1mm
encoder: shielded cable 2x0.5mm
F: LUMI built-in antenna
G: Electrolock
Elements of the complete installation
G
2 x 0,75mm 2
(max. 20m)
2
TC
TA

The electrolock is obligatory for operators without lock
(MA210 and MA250). For operators with lock, the
electrolock must be used for gate leaf lengths of over
1.8m.
*NOTE: the electrical installation of the operator can be
done correctly and straightforwardly using the cable with
AYCY8 code, which ERREKA can supply by metre. This cable
has the characteristics 4x1mm
and was developed specifically for this use.
English
2 x 0,5mm 2
(max. 20m)
RG-58/U
2 x 0,5mm 2
(max. 20m)
2
3 x 1,5mm
(max. 30m)
E248A
2 2 2
+2x1mm + ((2x0.5mm ))
5
