9.3. MA350

Measurement method
Real-time, 5 wavelength spectrum analysis by
measuring the rate of change of transmitted light
due to continuous particle deposition on filter.
Measurement at 880 nm interpreted as concentration
of Black Carbon ('BC'). Measurement at 375 nm
interpreted as Ultraviolet Particulate Matter ('UVPM')
indicative of woodsmoke, tobacco, and biomass
burning.
Measurement wavelengths
880 nm, 625 nm, 528 nm, 470 nm, 375 nm
DualSpot® Loading Compensation
Real-time analysis by measuring the rate of change in
absorption of transmitted light due to the continuous
collection of aerosol on filter. Simultaneous collection
on two spots in parallel at different flow rates.
Timebases
1, 5, 10, 30, 60, or 300 seconds
Flow Rates
Internal pump provides 50, 100, or 150 ml/min,
DualSpot® compensation not compatible with all
settings
Pump Options
Standard internal diaphragm pump, Optional internal
brushless diaphragm pump.
Flow Control
Internal mass flowmeters with closed-loop control
Filter Material
Polytetrafluoroethylene (PTFE)
Filter Capacity
MA350 Filter Tape Cartridge with PTFE material (85
sampling locations)
Sensors
Accelerometer, Relative Humidity, Temperature,
Altimeter/Barometer
Dimensions
L: 199.90 mm (7.87 in), W: 99.82 mm (3.93 in), D:
69.85 mm (2.75 in)
Weight
965 grams (34.04 ounces)
50 microAeth MA Series MA200, MA300, MA350 Operating Manual
®
Memory
16 GB internal flash memory, providing multiple years
of data storage
On-board user interface
Low Power Screen, 3 Buttons
Location services
GPS with Internal Antenna
Date/Time format
ISO 8601 with satellite synchronization
Wireless
802.11b Wi-Fi with AES hardware encryption,
Bluetooth Low Energy
Connections
Via sealed connector for 3.3V TTL Serial and DC
power input, USB 2.0 on inside panel
Communications
USB and wireless connectivity to cross-platform
microAeth® Manager software available on macOS®
and Windows®. microAeth Manager software is
included and facilitates settings configuration,
calibration routines, downloading data, and
uploading new instrument firmware.
Battery
Internal 3.6V 12800 mAh (46.08 Wh) rechargeable
lithium-ion battery
Recharging
Sealed connector for fast charging DC via barrel jack
AC adapter (~11.75 hours to full charge, instrument
turned off) or USB charging on inside panel (~25.75
hours to full charge, instrument turned off)
Power Supply Adapter
Input: 100~240 VAC 50/60Hz 0.4A, Output: 5VDC /
2A, with option for Type A, C, G, or I plug
Operating Environment
0 ~ 40 °C operating, non-condensing.
Specifications are subject to change without notice.
AethLabs
All specifications are subject to change without notice. Patents pending.
microAeth® is a registered trademark of microAeth Corporation dba AethLabs.
Aethalometer® and DualSpot® are used under license from Magee Scientific Corporation.
microAeth® MA Series MA200, MA300, MA350 Operating Manual, October 2017, rev01
AethLabs microAeth
®
MA Series MA200, MA300, MA350 Operating Manual 51
