- Page 1 ASSEMBLY INSTRUCTIONS Description : ROUND VERNON COUNTER HEIGHT TABLE Dimension 36”x36”.H Cube Size : 38”x38”x6.9” NW: 37.4 LBS GW: 44 LBS ROUND VERNON COUNTER HEIGHT TABLE - 1 -...
- Page 2 Large lock washer washer ( Φ8.5xΦ19mm) ( Φ8.5xΦ11mm) Hexagon nut Wrench (M8x13mm) (M13mm) Small flat Small lock washer washer ( Φ6.5xΦ13mm) ( Φ6.5xΦ9mm) Bolt Allen key (M6x35mm) (M4) Medium flat washer ( Φ6.5xΦ16mm) ROUND VERNON COUNTER HEIGHT TABLE - 2 -...
- Page 3 Attach legs (B) to the pedestal (C) with washers (1), (2) and nuts (3). Tighten with wrench (4). STEP 2 Put the cross piece (D) on top of the pedestal, and attach with bolts (7), washers (5), (6). Tighten with Allen key (8). ROUND VERNON COUNTER HEIGHT TABLE - 3 -...
- Page 4 STEP 3 Carefully place the cross frame (from Step 2) on bottom side of the table top (A), attach with bolts (7), washers (9), (6). Tighten with Allen key (8). ROUND VERNON COUNTER HEIGHT TABLE - 4 -...
