Summary of Contents for Monoprice Blackbird30916
- Page 1 Blackbird™ 4K HDMI® 4x4 Mini Matrix P/N 30916 User's Manual...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. ... -
Page 3: Customer Service
If you have any problem with your order, please give us an opportunity to make it right. You can contact a Monoprice Customer Service representative through the Live Chat link on our website www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-... -
Page 4: Package Contents
PACKAGE CONTENTS Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice Customer Service for a replacement. 1x 4x4 HDMI® matrix 1x IR remote control... -
Page 5: Remote Control
Rear Panel 1. OUT X: HDMI® connectors for connecting up to four HDMI displays. 2. IN X: HDMI connectors for connecting up to four HDMI source devices. 3. RS-232: Phoenix connector for connecting a PC for RS-232 remote control. 4. EDID: DIP switches for setting the Extended Display Identification Data (EDID), which determines the resolution and audio settings for the input source devices. -
Page 6: Sample Connection Diagram
SAMPLE CONNECTION DIAGRAM INSTALLATION Perform the following steps to install this matrix into your home theater system. 1. Ensure that all equipment to be connected is powered off and unplugged from its power source. 2. Place or mount the matrix in its intended location. 3. - Page 7 4. Using a High Speed HDMI® Cable (not included), plug one end into one of the IN ports on the matrix, then plug the other end into the HDMI output on one of your HDMI video source devices. Repeat for up to three additional HDMI video source devices.
- Page 8 For example, if you have 4K, 1080p, and 720p displays connected, the maximum common video resolution is 720p, so you need to set the EDID DIP switches to set the maximum video resolution to 720p. The following table shows the various DIP switch settings for each of the different video and audio combinations.
- Page 9 RS-232 CONTROL This matrix can be controlled from a computer using an RS-232 serial data connection. When you make the physical serial connection, you will be able to see the matrix on your PC as a USB device. If it is not already powered on, press the POWER button on the front panel to power on the matrix.
- Page 10 4. Reboot: Click the Reboot button to restart the matrix. 5. Enable Beep: Click the Enable Beep checkbox to enable or disable audio feedback from the matrix. 6. Power On: Click the Power On checkbox to turn the matrix on or off. 7.
- Page 11 2. Copy EDID From: Use the first drop-down list to select the display from which the EDID data will be copied, then use the second drop-down list to select the video source device, and finally click the Set button to copy the EDID capabilities. 3.
- Page 12 3. Arrows: Click the back or forward buttons to cycle the selected video source device for the specific OUTPUT. Upgrade Page The Upgrade Page allows you to upgrade the matrix's firmware. 1. Open: Click the Open button to open the file browser to select the firmware file. Firmware files have a .FW file extension.
-
Page 13: Technical Support
TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates. - Page 14 Blackbird™ is a trademark of Monoprice Inc. HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Dolby® and the double-D symbol are registered trademarks of Dolby Laboratories. Dolby TrueHD™...
