  • Page 1 ElektroPhysik Technical Manual and Operating Instructions Ultrasonic Coating Thickness Measuring System QuintSonic 7...
  • Page 2 Dr. Steingroever GmbH & Co. KG Pasteurstr. 15 50735 Köln Deutschland Tel.: +49 221 752040 Fax.: +49 221 7520467 Internet: http://www.elektrophysik.com/ Mail: info@elektrophysik.com © ElektroPhysik Version 0.92 13.08.2013 /Rh/bo-r Subject to change without notice © ElektroPhysik QuintSonic 7 2 von 184...

  • Page 3: Table Of Contents

    Introduction .......................... 8 General Remarks ......................8 Field of Applications ......................8 Measuring Procedure ...................... 8 The QuintSonic 7 Measuring System ................9 First Steps .......................... 11 Insert batteries and connect sensor ................11 Switching-on and taking readings .................. 12 2.2.1...
  • Page 4 Icons to identify invalid echoes ................65 7.4.8 Quit the A-scan image ................... 66 Echo Signal Processing ....................67 Introduction ........................67 Levels of Processing ..................... 68 Preprocessing ....................... 68 8.3.1 General remarks ....................68 8.3.2 Time-clipping ......................69 © ElektroPhysik QuintSonic 7 4 von 184...
  • Page 5 General remarks / How to call the data base............92 11.2.2 Directories ......................92 11.2.3 Batches ........................97 11.2.4 Parameter sets ....................104 Setting Parameter Sets ....................106 12.1 Edit a parameter set (alphanumerically) ..............106 © ElektroPhysik QuintSonic 7 5 von 184...
  • Page 6 15.4 Submenu “Active batch” ....................150 15.5 15.5.1 Properties ......................150 15.5.2 Readings ......................150 15.5.3 Configuration ....................... 151 Submenu “Setup” ......................152 15.6 15.6.1 General remarks ....................152 15.6.2 Display ......................... 152 © ElektroPhysik QuintSonic 7 6 von 184...
  • Page 7 Error messages and trouble shooting ................173 21.2 Statistical Terms ......................178 21.3 Safety Notes ........................ 180 21.4 Declaration of Conformity ....................181 21.4 After-sales Service ...................... 182 Change-history ........................ 183 Index ..........................183 © ElektroPhysik QuintSonic 7 7 von 184...

  • Page 8: Introduction

    50 µm. 1.3 Measuring Procedure The working principle of QuintSonic 7 is based on the reflection of ultrasonic waves at the interfaces between the individual layers of a coating system. For measurement, a liquid or pasty couplant is applied on the sample at the point of measurement. The sensor is put on the measuring spot.

  • Page 9: The Quintsonic 7 Measuring System

    Special feature of QuintSonic 7: A-scan images (see section 7) are shown directly on the gauge display for immediate quality assessment of the readings obtained without the need to connect a computer.
  • Page 10 USB interface for connecting a mains unit, headphones, a footswitch and or an alarm device. If only single functions are requested, an RS232 adapter cable as well as an IR/ USB converter unit (for connecting a PC) can be supplied. © ElektroPhysik QuintSonic 7 10 von 184...

  • Page 11: First Steps

    The red marking at the connector must be positioned correctly to the red marking of the socket. Fully engage the sensor plug into the sensor socket all the way to the stop. © ElektroPhysik QuintSonic 7 11 von 184...

  • Page 12: Switching-On And Taking Readings

    The “ON/OFF“ -button is located on the left side of gauge. ON/OFF-button Function keys Command and navigation block Prior to the initial operation of the gauge, please proceed according the instructions below. The menu will guide you through the procedure. © ElektroPhysik QuintSonic 7 12 von 184...

  • Page 13: Setting Language

    For the initial operation, there is no need to carry out this function. Therefore press the “NO” function key. To complete the initialisation procedure, the type of power supply is displayed. Do not change this setting. Just confirm by pressing “Finish” (Done). © ElektroPhysik QuintSonic 7 13 von 184...

  • Page 14: Taking Readings

    Hold the grey spring-loaded sleeve of the sensor with one hand and place the sensor vertically onto the measuring spot where you have applied the couplant. Push the sensor sleeve fully down to the stop. Measurement will launch automatically. This will take around one second. © ElektroPhysik QuintSonic 7 14 von 184...
  • Page 15 Briefly press ON/OFF-button to switch off the gauge. The figure above shows all data displayed on the measuring screen. For more details please refer to the following sections of this manual. © ElektroPhysik QuintSonic 7 15 von 184...

  • Page 16: Description Of The System

    The command and navigation key block may also assume different functions: Press OK to confirm settings, store values or select items from the menu. © ElektroPhysik QuintSonic 7 16 von 184...

  • Page 17: Sockets And Interfaces

    (see sections 15.6.4 and 17). Note: This manual only describes the operation of the QuintSonic 7 as an ultrasonic coating thickness gauge. If you wish to connect the display unit to an F, N or FN sensor, please refer to the MiniTest 7400 operating instructions.

  • Page 18: Power Supply

    3.1.4.1 Batteries and storage batteries The QuintSonic 7 gauge is powered by a set of four alkaline-manganese cells, 1.5V, AA LR6 size, (batteries included in the standard supply schedule). As an alternative, it may be operated on rechargeable NiMH storage batteries (type AA-HR6 or via a plug-in mains unit (available as an option).

  • Page 19: Sensor

    Note: The adapter is not designed for frequent change. 3.1.4.3 USB-Interface The QuintSonic 7 can also be powered via the USB interface of a PC. For this purpose, please use the USB adapter cable (supplied as an option). Connect the gauge to your PC. The gauge switches on automatically.
  • Page 20 They are stored in the sensor itself to make them available at any time. They will be retained even if the sensor is connected to another QuintSonic 7 gauge, in other words, you can use a QuintSonic 7 sensor and connect it to any QuintSonic 7 gauge as requested.

  • Page 21: Measuring Ranges

    # 2, echo positions can be obtained only in time intervals of 10.0 ns, 10.4 ns, 10.8 ns, etc. Intermediate values do not occur. Resolution is highest in the lowest measuring range, whereas it is lowest in the highest measuring range. © ElektroPhysik QuintSonic 7 21 von 184...

  • Page 22: User Interface

    User Interface 4 User Interface The following sections provide an overview of the most important QuintSonic 7 menu screens including a short description of the same. For more detailed information, please refer to the relevant paragraphs. For a complete description of the menu system, please see section 15.

  • Page 23: Measure Mode - Numerical And Graphical Screen

    On the upper right, the number of readings stored in the current batch is shown along with the name of active batch and the name of parameter set relating to this batch (bottom line). © ElektroPhysik QuintSonic 7 23 von 184...

  • Page 24: Measure Mode - Large Numerical Screen

    To call this screen the “Graphics” parameter must be disabled. Go to the “Configuration” submenu and press the “Configuration” function key (see section 15 5. 3 “Configuration”). © ElektroPhysik QuintSonic 7 24 von 184...

  • Page 25: Measure Mode - A-Screen Image With Echo Signal

    The broken lines represent the clipping lines. For their signification and use please refer to section The A-scan image also includes a zoom function to zoom in or out sections as requested (see also section 7.4). © ElektroPhysik QuintSonic 7 25 von 184...

  • Page 26: Statistics Screen

    All statistical values of a batch will be reported in tabular form. The figure above represents Layer 1. Statistics are available for each individual layer as well as for the total thickness. For more details on the statistical functions please refer to section 13. © ElektroPhysik QuintSonic 7 26 von 184...

  • Page 27: Main Menu

    Press the Help-key on the left to call up the help menu relating to the currently active menu. A context oriented help is available for many of the different screens. For more detailed information please refer to section 4.2. © ElektroPhysik QuintSonic 7 27 von 184...

  • Page 28: How To Navigate In The Main Menu

    User Interface 4.2 How to navigate in the main menu The numerous QuintSonic 7 functions can be accessed via the hierarchically structured user menu. The main menu represents the highest menu level. From the main menu you can get access to various submenus and their respective submenus or to other screens such as statistics or parameter screens.

  • Page 29: Parameter Setting

    Select “Setup” followed by “Display” and choose “Backlight”. Press OK and the parameter will change its state. If you press again, it will switch back, etc. The state highlighted state is being active. © ElektroPhysik QuintSonic 7 29 von 184...

  • Page 30: Setting Selection Parameters (Example: Language)

    If you have mistyped, you can delete the unwanted value from the entry line by pressing the “Delete” function key. If necessary, press repeatedly. © ElektroPhysik QuintSonic 7 30 von 184...

  • Page 31: Alphanumercial Parameter Entries (Example: Directory Name)

    For permanent input of capital letters, move to the CAPS-field. Enabling the CAPS-field sets an input mode in which all typed letters are in upper case (and vice versa). A bold-typed arrow will appear to indicate the CAPS-key is enabled. © ElektroPhysik QuintSonic 7 31 von 184...
  • Page 32 Once you have completed your text, press “Done“ to confirm. You will be asked whether to save changes or not. Press OK to confirm or ESC to abort. If you abort, the previous setting will remain valid. © ElektroPhysik QuintSonic 7 32 von 184...

  • Page 33: Calibration

    5.2 How to calibrate for the sound velocity QuintSonic 7 offers several methods for a sound velocity calibration. The methods are described in the following section. For the practical operation, please refer to section 12.1.4.4.
  • Page 34 Calibration b) Using the table of literature values The QuintSonic 7 menu offers two selection tables from which you can choose a sound velocity according to the material to be measured. In the table of ”literature values“ you will find a list of commonly used plastic materials and other materials such as steel, brass, wood, etc.
  • Page 35 Now enter the defined values of the individual layers into the table. Once completed, use QuintSonic 7 to take several measurements on the calibration standard. For each layer, the gauge will calculate an average from the set of readings you have taken.

  • Page 36: Measure Mode

    Particularities with ultrasonic coating thickness measurement systems After careful perusal of this manual you will be able to operate the QuintSonic 7 gauge correctly. Please note that apart from operating errors, there are a lot of other factors that might impair measurement.

  • Page 37: Limits To The Measurement Technique

    First the cross-sections of samples are measured by means of the QuintSonic 7 gauge. After this, the measuring system can be calibrated according to the results obtained by the cross-section. Through the calibration procedure, the correct sound velocities will be adjusted automatically.
  • Page 38 The QuintSonic 7 sensor features an integrated temperature compensation for the sound velocities of layers. The temperature compensation is adjusted to an average temperature coefficient of typical industrial coating materials.

  • Page 39: Settings To Make Prior To Measurement

    Use this batch for quick measurement action and if data processing or storage of parameters settings are not required. For using the “Direct Mode” go to the database and select “Direct Mode” (see also section 11.2.3.5). © ElektroPhysik QuintSonic 7 39 von 184...

  • Page 40: How To Create Or Select A Batch

    Please do also refer to section 9.2 (Section 9 “Tips and tricks”). © ElektroPhysik QuintSonic 7 40 von 184...

  • Page 41: How To Prepare Measurement

    For processing a signal emitted by an ultrasonic sensor, an appropriate reference signal is required. QuintSonic 7 autonomously checks the validity of the existing reference signal. If the reference signal is invalid, you will be asked to take a new reference signal (see screenshot below).

  • Page 42: Selecting A Couplant

    Main target is to ensure both, a maximum input of energy as well as a maximum output of energy (of the receiving signal). For this purpose, the couplant must feature appropriate acoustic properties. © ElektroPhysik QuintSonic 7 42 von 184...

  • Page 43: Checking / Carrying Out Calibration

    The suitability of the above listed couplants for this application has been carefully checked and approved by ElektroPhysik. If other couplants are used, user is responsible for measuring errors or damage to the sensor. Please note that any warranty claim will expire if the sensor is damaged by use of couplants other than those approved by ElektroPhysik.

  • Page 44: Taking Readings

    After measurement and if you want to take the gauge out of service, use a moist and soft cloth for cleaning the sensor surface. Dried up residue of couplant on the sensor is hard to remove and the sensor might be damaged when trying to clean from such residue. © ElektroPhysik QuintSonic 7 44 von 184...

  • Page 45: Measuring Procedure

    When taking repetitive measurements on the same spot, take care of the state of couplant. It must not dry up. If necessary, remove the used couplant and apply a new quantity. Make sure the couplant is evenly distributed over the measuring surface. © ElektroPhysik QuintSonic 7 45 von 184...
  • Page 46 Measure Mode Ideal sensor position. Example: Readings taken on a 3-layer sample © ElektroPhysik QuintSonic 7 46 von 184...

  • Page 47: Signification And Use Of A-Scan Images

    X-axis. In ultrasonic measurement techniques, this type of time diagrams are commonly referred to as “A-scan image. “ Like with the classical coating thickness gauges, also with the QuintSonic 7, data acquisition and evaluation are made automatically. Once the sensor is put onto the measuring object, the measuring procedure will launch automatically and the results are shown on display.

  • Page 48: Description Of A-Scan Image Types

    That’s why the verification of readings by means of the A-scan image should become a routine in ultrasonic measurement. 7.2 Description of A-scan Image Types QuintSonic 7 provides the following types of A-scan images: reference signal raw measuring signal...

  • Page 49: Raw Measuring Signal

    Please note that the A-scan image of the measuring signal is of no significance for the user, it only serves for servicing purposes. It is only mentioned in this manual for the sake of completeness and to enhance the understanding of the overall context. © ElektroPhysik QuintSonic 7 49 von 184...

  • Page 50: Echo Signal With Echo Lines

    Not all pulses that can be seen in the echo signal are actually fitted with an echo line. This is due to the clipping processes as selected and set by the user in order to cut out certain portions of the © ElektroPhysik QuintSonic 7 50 von 184...
  • Page 51 Most times, the position of the extracted echo signals as compared to the profile of curve seems to be totally random. For that reason, on the A-scan image, QuintSonic 7 does not use the raw © ElektroPhysik...

  • Page 52: Application

    This A-scan image represents the main tool for the user. It includes all relevant information on the correct system parameter settings and the effects thereof on the echo signal. The below sections are dedicated to the different aspects of this subject. In some paragraphs it will be referred to © ElektroPhysik QuintSonic 7 52 von 184...
  • Page 53 10%. The achievable maximum coupling index depends on the measuring object. Though the coupling index gives a useful hint with regards to the quality of coupling, the A-scan image will provide more detailed information on the conditions. © ElektroPhysik QuintSonic 7 53 von 184...
  • Page 54 They will be represented as irregular course of the zero line (noise floor). The strength of noise depends on the object to be measured. QuintSonic 7 offers several selection methods usually suppress such noise almost completely.
  • Page 55 7.3.3.5 for further details on such echoes. Echoes at layer interfaces are numbered from the left to the right. The reference number corresponds to the single coating thickness values as shown on the left of screen. © ElektroPhysik QuintSonic 7 55 von 184...
  • Page 56 Only the extremely thin layer will not be represented in the result. A special situation will be given if additional layer interfaces have been produced due to interruptions of the manufacturing process (see section 7.3.3.5). © ElektroPhysik QuintSonic 7 56 von 184...
  • Page 57 Such signal will not be show on the A-scan image. A glimpse on the echo diagram will enlighten this situation. eliminated through clipping eliminated through blocked domain example: unexpected echoes © ElektroPhysik QuintSonic 7 57 von 184...
  • Page 58 “true” layer interfaces. Any unwanted echo can be filtered out by means of the post- processor. Unwanted echoes are marked with an icon to indicate the reason why they have been filtered out (see section 7.4.7). © ElektroPhysik QuintSonic 7 58 von 184...

  • Page 59: How To Use The A-Scan Screen

    The A-scan image includes all necessary information on the quality of measurement, probable interferences as well as on the currently set filtering and selection methods. To enable convenient reading of the A-scan image, QuintSonic 7 provides several adjusting options in order to optimise the currently visible image sections.
  • Page 60 A-scan image indicating the full time and amplitude domains (100%). The signal curve is very small and not clearly visible. The settings as described below will allow you to optimise the image section accordingly. © ElektroPhysik QuintSonic 7 60 von 184...

  • Page 61: Zoom-In And Zoom-Out In Amplitude Direction

    0 before carrying out the zoom function. Hence, the left time limit will be fixed at zero after zooming. Only the right time limit has changed. © ElektroPhysik QuintSonic 7 61 von 184...

  • Page 62: Graphics Cursor And Displacement In Time Direction

    (Pan). However, the point of time 0 or the limits of measuring range cannot be exceeded. If the total measuring range (zoom factor 1) is visible, no displacement can be made. © ElektroPhysik QuintSonic 7 62 von 184...

  • Page 63: Zoom And Position Indicator

    The three remaining items are described in this section. With “Echo position” you can call the echo position of the current reading. “Zoom 100%” and “Auto zoom” provide two different zoom options. Select one of the items and press OK to confirm. © ElektroPhysik QuintSonic 7 63 von 184...
  • Page 64 The Auto zoom function automatically adjusts the image section of the current A-scan image in a way that all echoes can be seen at maximum size (optimal image section). After carrying out this function, the A-scan image reappears. © ElektroPhysik QuintSonic 7 64 von 184...

  • Page 65: Measure Mode With A-Scan Image Being Shown

    The echo has been sorted out by a blocked domain (section 8.5.4) Echo beyond the adjacent domains of expectation (section 8.5.5). The echo has been sorted because of admissible number criterion (section 8.5.6). © ElektroPhysik QuintSonic 7 65 von 184...

  • Page 66: Quit The A-Scan Image

    After you have reached the total image section you can quit the A-scan image by pressing ESC again. The query as shown on the left appears. Press ESC to quit the A-scan image or ESC to stay with the image. © ElektroPhysik QuintSonic 7 66 von 184...

  • Page 67: Echo Signal Processing

    For this purpose, the QuintSonic 7 sensor disposes of a number of filtering and selection methods. Please refer to the section to follow for a detailed description of their function, parameter setting and application.

  • Page 68: Levels Of Processing

    One half of the sample will be used to analyse the layers of the coating system. The other one will be used for taking readings by means of the QuintSonic 7. This way, an appropriate parameter set can be determined along with the matching sound velocities. The parameter set resulting from this service will be made available to the user.

  • Page 69: Time-Clipping

    By means of the amplitude-clipping, portions of the echo signal curve containing unwanted echoes can be extracted from the echo extraction. QuintSonic 7 offers three different clipping methods adapted to different settings of task. According to the clipping method, one or two adjustable limits are used.
  • Page 70 A value around 0.5% presents a good compromise. Basically, the evaluation of local extremes should only be activated if no correct echo extractions can be achieved in the standard mode. © ElektroPhysik QuintSonic 7 70 von 184...
  • Page 71 “inverse” function for individual time domains. This function will turn evaluation into the inverse direction enabling to extract also such kind of echoes . The domain clipping parameters can be set numerically (see section 12.1.2.1) or graphically via the A-scan image (see section 12.2.2.2.2). © ElektroPhysik QuintSonic 7 71 von 184...
  • Page 72 (given the correct setting of the amplitude limits). In failure of this, any unwanted echoes have to be extracted first together with the wanted echoes to be later © ElektroPhysik QuintSonic 7 72 von 184...

  • Page 73: Least-Squares Optimisation

    If clear corrections occur and if measurements are reproducible, the optimisation function should be enabled for further measurements. For more details on the optimisation please see also section 9 “Tips and Tricks”. © ElektroPhysik QuintSonic 7 73 von 184...

  • Page 74: Postprocessing

    Only the remaining echoes will be considered as being unwanted echoes and can be suppressed accordingly by using appropriate methods. QuintSonic 7 offers a number of postprocessing options that partially complement each other or can be used alternatively. The postprocessor runs a set of possible selection mechanisms in a fixed sequence.

  • Page 75: Manual Echo Selection

    This selection methods always suits if the number and sequence of layer echoes and unwanted echoes is known and constant and if no sporadic interferences occur that might temporarily change this sequence. © ElektroPhysik QuintSonic 7 75 von 184...

  • Page 76: Blocked Domains

    The parameters for defining blocked domains can be made numerically (section 12.1.4.2) or graphically via the A-scan image (section 12.2.3). © ElektroPhysik QuintSonic 7 76 von 184...

  • Page 77: Expectancy Domains

    An expectancy domain is completely defined by its upper and lower limits (layer thickness values). These limits result form a nominal value and the respective tolerances. An expectancy domain can be either enabled or disabled. Disabled domains will be jumped and © ElektroPhysik QuintSonic 7 77 von 184...

  • Page 78: Number Criteria

    In this menu you can set the number of layers to be evaluated. Generally, this number is known to the user. The number you have set in this menu will be used by the criteria “First echoes”, “Last echoes” and “Largest echoes” as described later in the paragraph. © ElektroPhysik QuintSonic 7 78 von 184...
  • Page 79 If you adjust the number of layers to be detected to 1, the system will only evaluate the wall thickness. If you set this number to > 1, the system will always consider the last thickness value to be the wall thickness. © ElektroPhysik QuintSonic 7 79 von 184...
  • Page 80 5 echoes (section 8.5.3) because you expect 5 layer thickness values and at the same time, adjust the number of layers to 2 (section 8.5.6.1). As a consequence of such setting, only 2 thickness values would appear instead of 2. © ElektroPhysik QuintSonic 7 80 von 184...

  • Page 81: Tips And Tricks

    For that reason, ElektroPhysik offers a cross-section service with later optical evaluation of the sample. It is highly recommended to use this service: If the sound velocities in the materials concerned are not known, such cross-section evaluation will be required anyway for obtaining reliable and precise measuring results.

  • Page 82: Amplitude Clipping With Optimisation Enabled

    For measuring samples with a high level of unwanted varying echoes (as it often occurs in inhomogeneous materials) it is recommended to disable the optimisation function (see 8.4) as the reproducibility of readings will improve if this function is disabled. © ElektroPhysik QuintSonic 7 82 von 184...

  • Page 83: Inhomogeneous Bases

    “real” echoes. However, no certainty will be given. Due to a very small reflection factor you may risk to oversee echoes you might not expect at the instant of time concerned. © ElektroPhysik QuintSonic 7 83 von 184...

  • Page 84: Interaction Of Preprocessor, Optimisation And Postprocessor Parameters

    As a consequence, it will not be considered any more in any further subsequent processing stage. If you find an echo marked other than expected, it is recommended to check at which stage it has actually been © ElektroPhysik QuintSonic 7 84 von 184...
  • Page 85 Tips and tricks filtered out. This situation occurs more frequently than expected, especially if several postprocessing selection criteria have been activated at the same time. © ElektroPhysik QuintSonic 7 85 von 184...

  • Page 86: Application Examples

    9.3) without any changes being necessary. The expected layer interface echo will be extracted correctly. It will not be necessary to use the postprocessor function. However, there is one particularity to be seen on the A-scan image: © ElektroPhysik QuintSonic 7 86 von 184...

  • Page 87: Two-Layer Paint On Steel

    The large negative echo (2) is typical for a transition from plastic to metal. Metals always exhibiting a clearly higher acoustic impedance than plastics, the echo at the transitional layer will always be a large negative one. For that reason, such interface layers can be easily identified. © ElektroPhysik QuintSonic 7 87 von 184...

  • Page 88: Thin One-Layer Paint On Body Sheet

    Furthermore, the back wall echo from the painted sheet has been extracted. It can be easily be suppressed by setting a blocked domain far away from the domain to be processed. © ElektroPhysik QuintSonic 7 88 von 184...

  • Page 89: Wall Thickness Measurement

    In the above example, a coextruded foil of different materials is concerned. The thickness of the individual layers varies significantly. To make sure all echoes will be extracted, the global clipping limits have been set to ±1%. © ElektroPhysik QuintSonic 7 89 von 184...
  • Page 90 0 and ranging until the end of measuring range. Five layer interface echoes have been extracted, hence five layer thickness values have been provided as a result. © ElektroPhysik QuintSonic 7 90 von 184...

  • Page 91: Data Management

    11.1.2 Memory capacity / using the data memory The memory of QuintSonic 7 disposes of a data memory for at total of 300 batches and parameter sets (e. g 200 batches and 100 parameter sets) to store a maximum of 250,000 readings.

  • Page 92: Data Base

    (left screen). This is an intermediate position. A directory can be divided in to subdirectories. Once you have found the requested position, press the function key “Actions”. Choose “New Directory” and press OK to confirm. © ElektroPhysik QuintSonic 7 92 von 184...
  • Page 93 Use arrow up/down keys to select the directory or the directory entry (batch, parameter set) you wish to delete. Your selection will be greyed out. Press function key “Actions” and select “Delete”. Press OK to confirm. © ElektroPhysik QuintSonic 7 93 von 184...
  • Page 94 A parameter set associated to one or several batches cannot be deleted. Caution! Data will be deleted irretrievably and cannot be restored any more. For that reason, the delete function should be used with caution! © ElektroPhysik QuintSonic 7 94 von 184...
  • Page 95 It may occur that during the move procedure a message will appear “Memory optimisation in progress! Please wait…”. This is for internal reasons only and not of any importance to the user. The directory entry has been moved to the requested position. © ElektroPhysik QuintSonic 7 95 von 184...
  • Page 96 The current name appears in the alphanumerical entry field. You can change it now (see section 4.3.4 “Alphanumerical entries”. )The user name will persist. The name has been changed and the new directory name appears on the directory tree. © ElektroPhysik QuintSonic 7 96 von 184...

  • Page 97: Batches

    A alphanumerical entry field appears. Enter a batch name (see section 4.3.4 “Alphanumerical entries”). A confirmation prompt will ask you whether to save the new name or not. Press OK to confirm or ESC to abort the creation of a new batch. © ElektroPhysik QuintSonic 7 97 von 184...
  • Page 98 The copy function facilitates the creation of a series of new batches or to copy settings from the Direct mode. The batch has been created and will appear on the directory tree. For parameter settings see section 12. © ElektroPhysik QuintSonic 7 98 von 184...
  • Page 99 Place the senor on the measuring object. The gauge switches automatically to measuring mode and the currently reading is shown. You may also press the OK key to switch to the measuring mode. © ElektroPhysik QuintSonic 7 99 von 184...
  • Page 100 The submenu “Active Batch” will appear. Choose “Configuration” and press OK to confrm. The “Configuration” submenu will appear. Choose “Parameter set” and press OK to confirm. Choose a parameter set from the list and press OK to confirm. © ElektroPhysik QuintSonic 7 100 von 184...
  • Page 101 As a result, the batch would contain a mixture of readings taken with the originally set parameters as well as readings taken with the new parameter set. Hence, consistency of this batch would not be given any more. © ElektroPhysik QuintSonic 7 101 von 184...
  • Page 102 Choose “Configuration” and press OK to confirm and to call the submenu “Configuration”. Move the cursor to “Parameter set” option and press function key “Edit”. The submenu “Parameter set” appears. Proceed according to section 12 “Setting Parameter Sets”. © ElektroPhysik QuintSonic 7 102 von 184...
  • Page 103 Furthermore, you should take into consideration that one parameter set may be associated to several batches. Once you change such parameter set, all batches associated to this parameter set will be concerned and any measurement will continue with the changed parameter set in all batches accordingly. © ElektroPhysik QuintSonic 7 103 von 184...

  • Page 104: Parameter Sets

    “Parameter” has been used. Press function key “Actions” to call this menu. Choose “New Parameter Set” from the submenu and press OK to confirm. © ElektroPhysik QuintSonic 7 104 von 184...
  • Page 105 11.2.4.3 Move a parameter set See section 11.2.2.3: “How to move a directory or a directory entry“. 11.2.4.4 Rename a parameter set See section 11.2.2.4: “How to rename a directory or directory entry“. © ElektroPhysik QuintSonic 7 105 von 184...

  • Page 106: Setting Parameter Sets

    You can edit a parameter set you have chosen from the database or a parameter set associated to a currently active batch. If you have changed the parameter set of a currently active batch, QuintSonic 7 offers the possibility to repeat the processing of the previous measurements under the use of the changed parameter set.
  • Page 107 One parameter set may be associated to a number of existing batches containing readings. Once you change this parameter set, any readings to be taken in the associated batch will be made with the changed parameter set. © ElektroPhysik QuintSonic 7 107 von 184...

  • Page 108: General

    For a description of the and the use of such parameters please refer to sections 8.3 and 8.4. The parameter group “Clipping” includes a submenu. Choose “Clipping” and press OK to call this menu. © ElektroPhysik QuintSonic 7 108 von 184...
  • Page 109 Use the arrow up/down keys to scroll through the complete table. Note: A domain can not be activated before both numerical parameters of this domain have been defined. © ElektroPhysik QuintSonic 7 109 von 184...

  • Page 110: Optimisation

    A domain can not be activated before the numerical parameter of this domain has been set. 12.1.3 Optimisation The optimisation function that follows the clipping can be enabled or disabled as requested. For more details see section 8.4. © ElektroPhysik QuintSonic 7 110 von 184...

  • Page 111: Postprocessor

    Please note that the maximum of echoes to be processed will not be higher than the maximum number of layers you have specified. For more details on the postprocessor selection functions please refer to 8.5.6. © ElektroPhysik QuintSonic 7 111 von 184...
  • Page 112 For more details on the description, significance and use of the blocked domains please refer to section 8.5.4. Note: A domain can not be activated before all numerical parameters of this domain have been set. © ElektroPhysik QuintSonic 7 112 von 184...
  • Page 113 Once enabled, it will be automatically used by the postprocessor. For more detailed information the significance and use of expectancy domains please refer to section 8.5.5. Note: A domain cannot be enabled before all numerical parameters of this domains have been set. © ElektroPhysik QuintSonic 7 113 von 184...
  • Page 114 12.1.4.4.1 Direct entry Select “Direct” to call a numerical entry field. Enter the value for sound velocity. Unit of measure is m/s. For entry of alphanumerical para- meter values please refer to section 4.3.4. © ElektroPhysik QuintSonic 7 114 von 184...
  • Page 115 Finally, you will be asked whether to create a new entry for the material data in the user value table. Press OK to create such entry or ESC to abort. © ElektroPhysik QuintSonic 7 115 von 184...
  • Page 116 A table appears with customer set materials and their respective sound velocities. This table must have been filled in previously with user values (see section 12.1.5). Use arrow up/down keys to select a material. Press OK confirm. © ElektroPhysik QuintSonic 7 116 von 184...
  • Page 117 Enter the thickness values of the calibration standard (5 maximum) into the table (for input of numerical parameter values please refer to section 4.3.2). © ElektroPhysik QuintSonic 7 117 von 184...

  • Page 118: Edit The User-Values Table

    12.1.5 Edit the User-values table 12.1.5.1 Add a new material Proceed according to section 12.1.4.4.3 to call the submenu “user values”. Here, it is of no importance, which layers you have selected. Press function key “Add”. © ElektroPhysik QuintSonic 7 118 von 184...
  • Page 119 A confirmation prompt appears to ask you whether to save the name or abort. Press OK to save or ESC to abort. If you confirm, the new material entry will be created and listed on the table for further use. © ElektroPhysik QuintSonic 7 119 von 184...

  • Page 120: Edit A Parameter Set (Graphically)

    A-scan image or enter the same into the system. If a parameter set has been changed, QuintSonic 7 offers the possibility to repeat the processing of previous readings taken with the original parameter set without the need to repeat measurements, i.e.

  • Page 121: How To Call The Menu

    Select requested clipping method and press OK to confirm and activate your selection. 12.2.2.2 Clipping limits Any further editing procedure depends on the clipping method you have selected. Please refer to sections 12.2.2.2.1 to 12.2.2.2.3). © ElektroPhysik QuintSonic 7 121 von 184...
  • Page 122 Use arrow up/down keys to adjust the lower clipping limit. The lower solid cursor line will detach from the former lower clipping line and assumes the position you adjust to. Once the setting complete, press OK. © ElektroPhysik QuintSonic 7 122 von 184...
  • Page 123 A-scan image. Note: According to your clipping limit changes, some of the formerly visible echo lines may disappear and new ones appear accordingly. The echo signal, however, will remain unchanged. © ElektroPhysik QuintSonic 7 123 von 184...
  • Page 124 To create a clipping domain for the first echo, place the cursor in front of the echo pulse. Make sure to adjust the amplitude limit so that the echo will clearly protrude. Press OK to confirm. © ElektroPhysik QuintSonic 7 124 von 184...
  • Page 125 You can repeat the procedure for the second echo. Before calling the menu, make sure the cursor is positioned on the right in front of the clipping domain you have just created. © ElektroPhysik QuintSonic 7 125 von 184...
  • Page 126 Press function key Help/Extra to call the A-scan image. Choose “clipping limits” followed by “Delete”. Once you have confirmed “Delete” by pressing OK, the A-scan image reappears. The selected domain has been deleted. © ElektroPhysik QuintSonic 7 126 von 184...
  • Page 127 Adjust the cursor to the new position of limit. Press OK to confirm. The limits have been displaced and the processes recalculated accordingly. The clipping domains have been successfully dimensioned and positioned ensure optimal noise suppression. © ElektroPhysik QuintSonic 7 127 von 184...
  • Page 128 To create a clipping domain for the first echo, place the cursor behind the second coupling echo. Make sure to adjust the amplitude limit so that the first layer interface echo will clearly protrude. Press OK to confirm. © ElektroPhysik QuintSonic 7 128 von 184...
  • Page 129 Also the second layer interface echo clearly shows the third clipping domain exactly starts at the point where the echo pulse penetrates the edge of blocked domain. © ElektroPhysik QuintSonic 7 129 von 184...
  • Page 130 Position the cursor in the domain to be edited. Press function key Help/Extras to call the A-scan menu. Select “Clipping limits” followed by “Edit”. The A-scan image appears and the cursor jumps back to the starting point of the clipping domain. © ElektroPhysik QuintSonic 7 130 von 184...

  • Page 131: Blocked Domains

    “true” echoes while the third one has been extracted from an interference. A blocked domain is to be created now in order to suppress any false echoes behind the second layer interface echo. © ElektroPhysik QuintSonic 7 131 von 184...
  • Page 132 “Create” (see above). The starting point of the blocked domain and the amplitude limit are to be changed. Position the cursor in the blocked domain to be edited. © ElektroPhysik QuintSonic 7 132 von 184...
  • Page 133 Position the cursor in the blocked domain to be deleted. Press function key Help/Edit to call the A-scan menu. Select “Blocked domains” followed by “Delete”. © ElektroPhysik QuintSonic 7 133 von 184...

  • Page 134: Expectancy Domains

    “true” echoes while the third one has been extracted from an interference. For each “true” echo one expectancy domain is to be created in order to suppress any false echoes located beyond these domains. © ElektroPhysik QuintSonic 7 134 von 184...
  • Page 135 Move the cursor to the left in order to position it behind the first layer interface echo pulse. This is to determine the end point of the first expectancy domain. Press OK to confirm. The creation of the expectancy domain has been completed. © ElektroPhysik QuintSonic 7 135 von 184...
  • Page 136 The A-scan image appears with the expectancy domain to be edited being high-lighted. Now the start point of expectancy domain could be edited. However, do not make any changes at this point. Simply press OK: © ElektroPhysik QuintSonic 7 136 von 184...
  • Page 137 As no valid echoes are available, no thickness values will be displayed. The same result will be obtained if you position the first expectancy domain behind the first layer interface echo. © ElektroPhysik QuintSonic 7 137 von 184...
  • Page 138 Press Help/Extras to call the A-scan image menu. Select “Expectancy domains” followed by “Delete”. Once you have confirmed “Delete” by pressing OK, the A-scan image reappears and the selected expectancy domain has been deleted. © ElektroPhysik QuintSonic 7 138 von 184...

  • Page 139: Statistics / Batches

    “Numerical Statistics”. First, the statistics as calculated for the total thickness will appear. Use the arrow-up key to scroll through the statistics of single layers in ascending order, press arrow-down key for descending order. © ElektroPhysik QuintSonic 7 139 von 184...

  • Page 140: Readings

    The list includes also readings marked by “X” Such readings have been deleted previously. Deleted readings will not be considered for the statistics calculation. Example: Layer 1 The use and interpretation is the same as under “Total layer”. © ElektroPhysik QuintSonic 7 140 von 184...

  • Page 141: Histogram

    To calculate a histogram, a minimum of 5 readings is requested. If layers are not available or if the number of readings taken is less than 5, the below message will appear. © ElektroPhysik QuintSonic 7 141 von 184...

  • Page 142: Trend Diagram

    To calculate a trend diagram, a minimum of 5 readings is requested. If layers are not available or if the number of readings taken is less than 5, the below message will appear. © ElektroPhysik QuintSonic 7 142 von 184...

  • Page 143: Help / Extras

    It will neither be printed out nor transferred to any other system. However, it will be read out and listed as a “deleted value” by ‘”QSoft 7“ © ElektroPhysik QuintSonic 7 143 von 184...

  • Page 144: Delete All Readings

    The deleted reading will be shown on the list of single readings, but will be marked by “X”. It will neither be considered for statistics calculation, nor will it be printed out or transferred to a PC. © ElektroPhysik QuintSonic 7 144 von 184...

  • Page 145: Data Output / Data Transfer

    Data Output / Data Transfer 14 Data Output / Data Transfer QuintSonic 7 is equipped with two data ports: RS 232 interface ® Infrared (IrDA 1.0) Readings and statistics of a batch can be transferred to a PC or printed-out on the data printer MiniPrint 7000 (optional accessory).

  • Page 146: Transfer Data To A Pc (Terminal Program)

    9. Sound velocity Items can be omitted as requested. Example # 2 Point the black IR window of QuintSonic 7 to the IR window of the MiniPrint 7000 data printer. Make sure no objects between the two windows disturb data transfer.
  • Page 147 4. Measuring values / Measuring values + deleted values 5. Remarks (Text entry filed with 5 lines) Use the RS232 data cable to connect QuintSonic 7 to your computer or point the IR interface of QuintSonic 7 to the IR interface of your computer or IR adapter.

  • Page 148: Data Transfer To A Pc (Qsoft 7)

    PC. That’s why, the histogram and trend diagram shown on your PC may include more details as compared to the representation on the QuintSonic 7 gauge. Due to the lower resolution, the QuintSonic 7 display might not show all details.

  • Page 149: The Menu

    Press OK to confirm your selection. 15.2 Submenu “Database“ See section 11.2 “Database”. 15.3 Submenu “Statistics” See section 13 “Statistics“. 15.4 Submenu “A-scan image” See section 7 “Significance and use of A-scan images” © ElektroPhysik QuintSonic 7 149 von 184...

  • Page 150: Submenu "Active Batch

    The following date will be listed: Batch name Date of creation Date of last modification User name If you press OK you can switch to the measure mode. 15.5.2 Readings See section 13. © ElektroPhysik QuintSonic 7 150 von 184...

  • Page 151: Configuration

    If you select ”Sensor reference measurement” and confirm by OK, a reference measurement will be launched (see section 6.4.1). Note: From measure mode, the configuration menu can also be called up by pressing the function key “Configuration”. © ElektroPhysik QuintSonic 7 151 von 184...

  • Page 152: Submenu "Setup

    15.6 Submenu “Setup” 15.6.1 General remarks QuintSonic 7 offers a number of global setting options. These options are all included in the “Setup” submenu. To call this menu, press the function key “Main menu”. Use arrow up/down keys to select “Setup”.

  • Page 153: Date / Time

    MiniPrint 7000 data printer or transferred to a PC. Make sure your PC is equipped with an IR interface. Once the IrDA option is enabled, a permanent connection between QuintSonic 7 and a PC or printer in direct proximity will be established. The PC will indicate a wireless connection being established.
  • Page 154 The data format “8D/1S/N“ (8 data bits, 1 Stop-Bit, No Parity) is preset and cannot be changed. Under “Transmission protocol” you can enable or disable the ElektroPhysik transmission protocol. Set to “ON” if you are using QSoft 7. Set to “OFF” if data transfer is made to another software. In this setting, data transfer is made in ASCII format with carriage return character (CR/LF).
  • Page 155 PC. If you wish to additionally store the readings in the QuintSonic 7, it is required to enable the “Transfer of readings into statistics”. To prevent a memory overflow, the maximum number of readings storable in the gauge should not be exceeded.

  • Page 156: User Preferences

     Loudspeaker: ON / OFF. If enabled, any acquisition of reading or key action will be confirmed by an audible signal. The earphone output will remain active. © ElektroPhysik QuintSonic 7 156 von 184...

  • Page 157: Gauge Specifications

    The gauge will switch off automatically after being idle for the period of time you set. Please note: In connection with the data transfer software QSoft7, the QuintSonic 7 is permanently switched  Entry accepted: 0, 5, 1, 1,5 or 2 s The “entry accepted time”...

  • Page 158: Special Functions

    A Total Reset will irrevocably delete all data and directories from the memory. All settings except the language setting will be reset to the factory settings. The Total Reset action will also delete all directories and batches, including readings, statistics and calibration values. © ElektroPhysik QuintSonic 7 158 von 184...

  • Page 159: Special Functions Menu

    After you have made the settings as requested, you may continue your current action. As a consequence, valuable time will be saved. © ElektroPhysik QuintSonic 7 159 von 184...

  • Page 160: Sensor Service Menu

    Once you have called up the A-scan image, operation will be according to section 7.4. The echo signal with its positions is identical with the one as used in the normal measure mode. © ElektroPhysik QuintSonic 7 160 von 184...

  • Page 161: Readjust The Magnetic Switch

    Example: A-scan image of reference signal 16.3.3 Readjust the magnetic switch QuintSonic 7 is equipped with a magnetic switch to monitor the contacting process and launch the measurement. This magnetic switch is factory set and generally does not need any readjustment.

  • Page 162: Readjust The Sensor Tip Echo Suppression

    The travel time taken by the signal to travel through the sensor tip is determined by the measuring system. QuintSonic 7 uses this value as a measure for the sensor tip temperature, i.e. as input variable for the temperature compensation (see section 6.2).
  • Page 163 The Menu once determined without recalibrating, measurement might be affected. To readjust the reference point for temperature compensation, please go to the menu as shown below. © ElektroPhysik QuintSonic 7 163 von 184...

  • Page 164: Connectable Accessories

    Connectable accessories 17 Connectable accessories 17.1 General remarks QuintSonic 7 features a 7-pin multi-purpose socket for connecting various accessories directly or via a multi-purpose connection box. 17.2 Direct connection This enables connection of one of the below accessorial devices. The foot switch offers an additional connection to the plug-in mains-unit.
  • Page 165 An optical or acoustical alarm device may be connected to the alarm output Electrical data: voltage: 3.6 V impedance: 330 Ohm  headphones, the internal loud speaker signal is transmitted (no picture) to the headphones, useful in noisy environment © ElektroPhysik QuintSonic 7 165 von 184...

  • Page 166: Connection Via The Multi-Purpose Connection Box

    USB or RS232 interface. As soon as you connect an RS 232 cable, the USB interface connection will be disabled and the RS232 interface enabled.  multi-purpose connection box with lateral USB interface © ElektroPhysik QuintSonic 7 166 von 184...

  • Page 167: Care And Maintenance

    The full capacity of older storage batteries can be restored through frequent charge and discharge cycles. For such purpose, special charger units should be used.  Remove the NiMH storage batteries if the QuintSonic 7 gauge is not in use for a longer period of time. ...

  • Page 168: Technical Data

    Stocking temperature range 0°C ... +50°C (caution when storing in a car, for instance) Dimensions 153 mm x 89 mm x 32 mm (basic unit without sensor) Weight 310 g (Gauge incl. batteries) © ElektroPhysik QuintSonic 7 168 von 184...

  • Page 169: Sensor

    Application standards European standard currently in the draft phase Parameter setting, control serial, ElektroPhysik transmission protocol, via sensor cable and data transfer Operating temperature +5°C ... +50°C range Stocking temperature 0°C ...
  • Page 170 ) at a sound velocity of 2375 m/s (average value for industrial paints) ) completely determined by the accuracy ) of sound velocity values; the statistical error contribution of the measuring system can be neglected ) according to DIN 55350, part 13 © ElektroPhysik QuintSonic 7 170 von 184...

  • Page 171: Supply Schedule, Accessories

    Supply Schedule, Accessories 20 Supply Schedule, Accessories 20.1 Supply schedule Description Item # ® QuintSonic 7 gauge and SIDSP sensor 80-163-0000 including: ® SIDSP sensor cable, straight, 1 m standard length USB adapter cable Software QSoft 7 Basic Edition on CD...

  • Page 172: Accessories

    3 connections and USB port incl. USB cable Software QSoft 7 Professional Edition on CD 80-901-1301 Manufacturer’s test certificate according to DIN 55350 M for QuintSonic 7 incl. one sensor Manufacturer’s test certificate according to DIN 55350 M for calibration foils ©...

  • Page 173: Appendix

    Note: If, for instance, 3 echoes are measured but only echoes as of position 4 are set to be active, no thickness calculation will take place. © ElektroPhysik QuintSonic 7 173 von 184...
  • Page 174 The password is too short. 3 Change password at least 3 characters! characters required at accordingly. minimum. A directory cannot be Only elements such as None. displaced. batches, parameter sets in the data tree can be moved. © ElektroPhysik QuintSonic 7 174 von 184...
  • Page 175 Some parameters beyond Some parameters have been None. measuring range. defined in a higher measuring range. After switch to a lower measuring range, the parameters are not active any © ElektroPhysik QuintSonic 7 175 von 184...
  • Page 176 Possible causes: please change it or contact “Changes not possible !” no sensor connected after sales service. loose probe connection cable damaged sensor defective “Sensor failure “” Please contact after-sales service. © ElektroPhysik QuintSonic 7 176 von 184...
  • Page 177 If no key action is possible or if the gauge cannot be switched off via the ON/OFF button, briefly remove batteries and reinsert to remedy. © ElektroPhysik QuintSonic 7 177 von 184...

  • Page 178: Statistical Terms

         Variation coefficient (Var.-coeff.) The variation coefficient is the standard deviation divided by the arithmetic mean. The variation coefficient is indicated in percent.  100 © ElektroPhysik QuintSonic 7 178 von 184...
  • Page 179 In addition to the spread, the cpk index also takes into account the location of midpoint as related to the specification limits.   Cpku   Cpko Cpk = Min  Cpkl, Cpku  where USL = Upper specification limit where LSL = Lower specification limit. © ElektroPhysik QuintSonic 7 179 von 184...

  • Page 180: Safety Notes

    Do only connect original accessories as recommended by the manufacturer of QuintSonic 7. Keep away from water The measuring unit is not waterproof. Keep in a dry place.

  • Page 181: Declaration Of Conformity

    Appendix 21.4 Declaration of Conformity ElektroPhysik, Pasteurstr. 15, D-50735 Cologne, Germany, manufacturer of QuintSonic 7, declare in sole responsibility that the products this declaration relates to is in conformity with the provisions of directive 89 / 336 / EEC (Electromagnetic compatibility), in Germany: EMVG (Gesetz über die elektromagnetische Verträglichkeit) of November, 9...

  • Page 182: After-Sales Service

    Dr. Steingroever GmbH & Co. KG Pasteurstr. 15 50735 Koeln, Germany Tel.: +49 221 75204-0 Fax: +49 221 75204-67 E-Mail: info@elektrophysik.com Please refer to our website for the local representative of ElektroPhysik in your country: http://www.elektrophysik.com/company/agencies-abroad.html © ElektroPhysik QuintSonic 7 182 von 184...

  • Page 183: Change-History

    Data output 148, 153, 155, 156 entry accepted time 156 external charger 18 Floating point 155 foot switch 17 Function key 17, 28, 161 Gauge specifications 169 Infrared 145, 146, 147, 148, 153, 155, 169 © ElektroPhysik QuintSonic 7 183 von 184...
  • Page 184 155, 157 single readings 151, 179 specification limits 180 storage battery 152 Supply schedule 172 switch off 18, 168, 175 Total Reset 13, 159 Transmission Protocoll 146 USL 180 variance 179 © ElektroPhysik QuintSonic 7 184 von 184...

Table of Contents
