Keypad Lock
Installation Instructions
P516-405
Model FE599
Important Information
You will need
Lock Programming Code
this code
information to
perform certain
functions using
six (6) digits
the lock keypad.
These are the
User Code A
User Code B
factory default
lock code
settings (see
four (4) digits
four (4) digits
Step 1).
Pin Wrench
AA Batteries (4)
Alternate Faceplate
Keypad
Key
Latch
1

Locate Programming Code and Preset User Codes

The programming code and the preset
user codes are printed on the yellow
stickers located on the back of the keypad
and/or on the installation sheet that came
in the box. Write these codes in the space
provided on the fi rst page.
Please go to http://monitoringcontrol.
verizon.com and follow the simple steps
provided in the online setup wizard.
This will enable you to add your Door
Lock device to the Home Monitoring and
Control Network.
Tools Needed
Phillips
OR
Web Support:
http://monitoringcontrol.verizon.com

Package Contents

Baseplate
Cover
Latch/Strike Screws (4)
Strike
Programming Code XXXXXX
User Code A xxxx
S/N x-xxxxxxxx
User Code B xxxx
Model FE599
2

Check Door Dimensions

If your door does not match the dimensions shown, go to
http://verizon.schlage.com for instructions on how to prepare
your door.
3

Install Strike Into Frame

Lever
Cover
Screws (2)
4

If Necessary, Change Latch Faceplate

Check edge of door to determine the type of faceplate required.
5
5

Install Latch

Latch must be fl ipped so that bevel faces toward door jamb.
2³⁄₈" (60 mm)
O
2³⁄₄" (70 mm)
2¹⁄₈" (53 mm)
Hole
(2)
6

Remove Sticker from back of Lock

Strike Screws
7

Install the Keypad

OR
Feed the cable under latch assembly as shown below. Then
slide the tailpiece through the hole as shown below.
5
Bevel
Jamb
Jamb
OR
(2)
Latch Screws
Tailpiece
