4.2 Communication objects JUNG KNX Sonos Gateway
The JUNG KNX Sonos Gateway has numerous communication objects and allows extensive operation of the Sonos system.
All objects relevant to the installation example are listed in the two tables below.
These objects are required in the SV Server for visualisation and operation later.
GLOBAL FOR GROUPS
FUNCTION TYPE KNX FUNKTION
Multimedia Playlist mode
SPECIFIC TO SLAVES
KNX GROUP ADDRESSES
WRITE SIZE (DPT)
Volume control 1 byte (5.001)
Play 1 bit (1.010)
Next/previous playlist 1 bit (1.007)
Next/previous title 1 bit (1.007)
Repeat all 1 bit (1.003)
Shuffle 1 bit (1.003)
Select playlist 1 byte (5.010)
Slave 1 – change group membership 1 bit (1.001)
Slave 2 – change group membership 1 bit (1.001)
READ SIZE (DPT)
Volume status 1 byte (5.001)
Playlist name/Song titel/Album 14 bytes (16.001)
Playing status 1 bit (1.010)
Play mode status "Repeat all" 1 bit (1.003)
Shuffle mode status 1 bit (1.003)
Current playlist 1 byte (5.010)
Slave 1 – group membership 1 bit (1.001)
Slave 2 – group membership 1 bit (1.001)
SMART VISU SERVER + SONOS 10
