TOSVERT VF-AS1/PS1 series
EtherNet/IP™ option unit Instruction Manual
1. Make sure that this instruction manual is delivered to the end use r of
EtherNet/IP™ option unit.
2. Read this manual before installing or operating the EtherNet/IP™ optio n unit. Keep
it in a safe place for reference.
3. All information contained in this manual are subject to change without notice.
Please confirm the latest information on our web site "www.inverter.co.jp".
IPE001Z
NOTICE
E6581580②

Advertisement

Table of Contents
loading

Related Manuals for Toshiba IPE001Z

Summary of Contents for Toshiba IPE001Z

  • Page 1 E6581580② TOSVERT VF-AS1/PS1 series EtherNet/IP™ option unit Instruction Manual IPE001Z NOTICE 1. Make sure that this instruction manual is delivered to the end use r of EtherNet/IP™ option unit. 2. Read this manual before installing or operating the EtherNet/IP™ optio n unit. Keep it in a safe place for reference.

  • Page 2: Safety Precautions

    E6581580 Safety precautions On the inverter and in its instruction manual, important information is contained for preventing injuries to users, damages to assets, and for proper use of the device. Read the instruction manual attached to the inverter along with this instruction manual to completely understand the safety precautions, the symbols and indications shown below.

  • Page 3: Safety Precaution

    E6581580 Limitation of use Safety precaution Never use this unit with any device other than TOSVERT VF-AS1/PS1 series inverters. Doing so may cause an accident. Handling in general Warning Never disassemble, modify or repair the product. Disassembling the product may cause electric shocks, fire or injuries. Never For repairs, call your sales/repair agency.
  • Page 4 E6581580 Wiring Caution Electrical construction work must be done by a qualified expert. Connection of input power by someone who does not have expert knowledge may result in electric shocks or fire. Turn off input power before wiring. Mandatory Wait at least 15 minutes and make sure that the charge lamp (on the inverter unit) is no longer lit.
  • Page 5 E6581580 Preface Thank you for purchasing the “EtherNet/IP™ option (IPE001Z)” for TOSVERT VF-AS1/PS1 inverter. By installing this board into the VF-AS1/PS1, data communication can be made with a host computer or other device via EtherNet/IP™ network. Before using this unit, carefully read and understand the safety precautions, this manual and the inverter instruction manual.

  • Page 6: Table Of Contents

    2.1. Outline·······························································································································6 2.2. RJ45 connector pin layout·································································································7 2.3. Example of connection to an EtherNet/IP™ ······································································7 2.4. LED indicator·····················································································································8 3. Installing the IPE001Z ···············································································································9 4. Parameters······························································································································10 4.1. Communication parameters ····························································································10 4.2. f851: Communication Loss Action Setting (Network Disconnection) ·····························12 5. Command & Setpoint selection (Local/Remote)······································································13 6.

  • Page 7: Overview

    E6581580 1. Overview The EtherNet/IP™ interface (IPE001Z) allows the VF-AS1/PS1 inverter to be connected into the EtherNet/IP™ network. 2. Names and functions The drawing below shows names and functions of main parts. 2.1. Outline Connector to the inverter Panel mounting tabs EtherNet/IP LED indicator (See 2.4)

  • Page 8: Rj45 Connector Pin Layout

    E6581580 2.2. RJ45 connector pin layout .2. RJ45 connector pin layout The EtherNet/IP™ card is equipped with two shielded RJ45 connectors. The shielding is connected to the drive ground. Use an STP (shielded twisted pair) Ethernet cable The transmission speed is detected automatically by the card (10 Mbps or 100 Mbps). The card can operate in half duplex or full duplex mode, whether connected to a hub or a switch and regardless of the transmission speed (10 Mbps or 100 Mbps).

  • Page 9: Led Indicator

    E6581580 2.4. LED indicator .4. LED indicator The LED shows the present status of the network and error. Port R Port L Link Color/ state Description No Link Flashing Green/Yellow Power Up testing Green ON Link at 100 Mbps “Port R” Yellow ON Link at 10 Mbps Green BLINK...

  • Page 10: Installing The Ipe001Z

    E6581580 3. Installing the IPE001Z VF-AS1/PS1 Install the EtherNet/IP™ option to as follows. *When this option is used together with the IO card option, attach this option to the front panel side. Turn off the input power of VF-AS1/PS1 and wait for at least 15 minutes and then check that the CHARGE lamp on VF-AS1/PS1 is no longer lit.

  • Page 11: Parameters

    E6581580 4. Parameters 4.1. Communication parameters Set up the inverter parameters as follows. These parameters do not take effect until the inverter is reset. If these parameters are not set to correct value, this unit can not work normally. And configure the option with EDS file. The EDS file can be downloaded from the following web site.
  • Page 12 E6581580 Communi Factory Title Function Description cation No. setting 0: Disconnection detection Communication2 time-out  0849 1: When communication mode enabled condition selection 2: 1+Driving operation Disconnection detection  0850 0.0~100.0 sec. extended time 0: Inverter stop, communication command, frequency mode open (by cmod, fmod) Operation 1: None (continued operation)

  • Page 13: F851: Communication Loss Action Setting (Network Disconnection)

    E6581580 4.2. f851: Communication Loss Action Setting (Network Disconnection) This parameter sets up the VF-AS1/PS1 response to a loss of communications with the EtherNet/IP™ network. 0: Stop and Communication release The inverter decelerates the motor to a stop and gives a t alarm (the leftmost LED t flashes).

  • Page 14: Command & Setpoint Selection (Local/Remote)

    E6581580 5. Command & Setpoint selection (Local/Remote) Indication to display Local/Remote mode is on the inverter unit (Refer to the inverter instruction manual for details). EtherNet/IP™ option command and setpoint are activated on Remote mode. Inverters have some switches to select the command and setpoint location. Following figure shows the diagram.
  • Page 15 E6581580 Example> < The example below shows how to configure the VF-AS1/PS1 for local/remote operation. F terminal ....Operating command R terminal....EtherNet/IP™ local/remote (Terminal in this example) switching RR/S4 terminal..Operation frequency command <Wiring> VF-AS1/PS1 Variable resistor for adjustment 1-10k ohm RR/S4 Operation command SOURCE SINK...

  • Page 16: Specifications

    Failure or damage caused by the use of the EtherNet/IP™ communication option for any purpose or application other than the intended one. All expenses incurred by Toshiba for on-site services shall be charged to the customer, unless a service contract is signed beforehand between the customer and Toshiba, in which case the service contract has priority over this warranty.
