SImx LHT0182 Installation Instructions

Microwave sensor

Advertisement

Quick Links

TROUBLESHOOTING
Malfunction
Cause
Wrong light-control setting selected
The load will not work
Load faulty
Mains is switched OFF
The load is always ON
Continuous movement in the detection zone
The sensor not mounted for detecting
movement reliably
The load is ON
without any identifiable
Movement occurred, but not identified
movement
by the sensor (movement behind wall,
movement of a small object in immediate
lamp vicinity etc)
Rapid movements are being suppressed to
The load will not work
minimise malfunctioning or the detection
despite movement
zone you have set is too small
MANUFACTURERS WARRANTY
This product is guaranteed by SIMX Ltd for 36 Months from the date of purchase against faulty materials
or workmanship which affects its designed ability to operate. During this period if the product has a
defect of this nature it will be repaired or replaced free of charge by SIMX with the same item, or a
similar one of higher specification. ON CONDITION THAT:
The buyer returns it to the seller from whom it was bought, freight paid.
The product has been bought by the user. ie a receipt/sales invoice is produced as proof of purchase.
The product has not been misused or handled carelessly, installed in anyway contrary to the installation
instructions, used on a supply voltage other than that indicated in the product specifications, or installed
in any unusually exposed or harsh environmental conditions.
This guarantee excludes liability for discolouration of paint or plastic, or any user serviceable parts. It
does not confer any rights other than those expressly set out above and does not cover any claims for
consequential loss or damage.
Our Goods come with guarantees that cannot be excluded under the New Zealand Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the Goods repaired or replaced if
the Goods fail to be of acceptable quality and the failure does not amount to a major failure.
Distributed by: Simx Limited | Ph: 09 259 1660 | Technical Support Ph: 09 259 1662
Email: sales@simx.co.nz | Web: www.simx.co.nz
Simx reserves the right to alter technical specifications without prior warning
Remedy
Adjust setting
Change load
Switch ON
Check zone setting
Securely mount enclosure
Check zone setting
Check zone setting
PUB1163 iss03 11/14
INSTALLATION INSTRUCTIONS
Model: LHT0182 Microwave Sensor
This sensor is an active motion detector, it emits high-frequency
electro-magnetic waves, 5.8GHz and receives their echo.
The sensor detects the change in echo from even the slightest
movement in the light detection zone.
A microprocessor then triggers the "switch light ON" command.
Detection is possible through doors, panes of glass or thin walls
in most applications.
More reliable at distance than using IR or optical sensors, as
there are no gaps in the detection zone.
!
TECHNICAL SPECIFICATIONS
Power supply:
220-240 VAC
Power frequency:
50Hz
Installation:
Indoors, surface mounting
Hf system:
5.8Ghz CW radar ISM band
<10mW
Transmission power:
Max rated load:
1200W 5A resistive (incandescent)
200W 2.5A (fluorescent and CFL)
Effective mounting height:
Up to 4.0 metres
Detection angle:
360°
Reach:
2 - 20m dia. Adjustable
Time setting:
5sec to 12min (approx)
Light control:
2~2000lux
Power consumption:
approx.0.9W
IP20
IP rating:
Temperature range:
-10°C ~ 55°C
IMPORTANT
!
We strongly recommend that this sensor is installed by a suitably qualified and registered electrician.
Please read the entire Installation Manual and Calibration instructions before installing this product.
All electrical work must be carried out in accordance with local and national electrical codes as applicable.
Always switch power off prior to installation.
A means of power isolation must be installed on the circuit for the purpose of safe access for any internal
cleaning, recalibration or maintenance.
This appliance is not intended for installation or calibration by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given
supervision or instruction concerning its use by a person responsible for their safety.
There are no user-serviceable parts in this product.
Any changes or modifications made or attempted to this product without the prior written approval of the
manufacturer will void any and all stated warranties. This excludes normal calibration of the Reach, Time
and Light control setting knobs as described in these installation instructions.
working LED
light sensor
