  • Page 1 USER GUIDE KS-Series Gas Fireplace 630457_1 KS User Guide...
  • Page 2 17 Carnforth st, PO Box 5277 Dunedin, New Zealand Email: info@escea.co.nz Web: www.escea.co.nz Phone: +64 3 478 8220 Distributed in Australia by: Escea Australia PTY LTD P.O. Box 176 Pennant Hills, Sydney, NSW 1715 Phone: 1800 460 832 Web: www.escea.com.au...

  • Page 3: Table Of Contents

    Contents Remote Control Layout Basic Operation Initial Start / Battery Placement Adjusting the Room Temp Fan Boost Effect Only Setting the Time Keylock Timer Operation Activate Timer De-activate Timer Auxiliary On/Off Button Over Temperature Shutoff Operation Sound and Smell Sounds Gas Control Valve Appliance Metalwork Smells...

  • Page 4: Remote Control Layout

    Remote Control Layout Display Shows temperature settings and status of timers and other functions On / Off Switches the appliance on and off. Minus Adjusts the temperature and time set- Plus tings down. NOTE: The fan will operate at its lowest settings. Adjusts the temperature and time Effect Only settings up.

  • Page 5: Basic Operation

    Basic Operation − Initial Start / Battery Placement Remove the battery cover on the rear of the remote. Insert the new “AA” size batteries, being careful of the polarity. You should now see on the display of the remote the time showing “0:00”. To turn the fire on, press the “POWER”...

  • Page 6: Keylock

    Keylock Should you wish to keep the fire from being tampered with by children or to discourage people from altering the temperature, you can engage a keylock function which stops the remote buttons from changing any settings. To engage the keylock simply press the EFFECT ONLY and FAN BOOST buttons (4 + 8) simultaneously until the display shows the padlock symbol.

  • Page 7: Auxiliary On/Off Button

    Remote Pairing Button The KS-Series fireplaces have a manual on/off button that should only be used for teaching the remote. The diagram below shows the location of this button. NOTE: Ensure the appliance has cooled down before using the manual on/off button to avoid coming into contact with...

  • Page 8: Over Temperature Shutoff Operation

    “Set” temperature. Your Escea gas fire has a setting where it will turn off the main burner once the “Room” temperature exceeds the “Set” temperature, leaving only the pilot lit. The main burner will re-light when the “Room” temperature falls back below the “Set”...

  • Page 9: Sound And Smell

    − Fan Escea gas appliances use electric fans to push heated air further into the room. It is not unusual for the fan to make a “whirring” sound when ON. This sound will increase or decrease in volume depending on the thermostatic settings.

  • Page 10: Cleaning The Logs / Glass (Df Series)

    Log and Glass Care WARNING: DO NOT ATTEMPT TO CLEAN THE GLASS WHILE IT IS HOT. NEVER OPERATE THE UNIT WITH THE GLASS REMOVED. Cleaning the Logs / Glass: Step 1: Remove the glass by unscrewing the four 1/4 turn fasteners located at the top of the glass (shown in the diagram below) and remove the bracket (shown below shaded grey).

  • Page 11: Cleaning The Logs / Glass (Dl Series)

    Troubleshooting Escea gas fires communicate both to and from the fire and remote. This enables the remote to provide some basic fault finding information that is useful in diagnosing faults with your gas supply or flue. NOTE: The remote will take a minute or two to receive and display the error from the fire. Pressing the plus or minus keys will update the remote.

  • Page 12: Cleaning The Logs / Glass (Ds Only)

    The valve solenoids have failed the pre-ignition test. A wire may have dislodged or the valve solenoid is faulty. • Check that the connections to each solenoid are secure and in place. The connections on the ends of the wires may need to be tightened (e.g. with a pair of Valve Solenoid pliers) to ensure a robust connection to the valve terminal.
