INSTRUCTION MANUAL
VR7600
Rack Mounted Zone Volume Controllers
ZONE 1
ZONE 2
ZONE 3
ZONE 4
ZONE 5
ZONE 6
Thank you
for choosing another quality product from Amperes Electronics.
VR series is available in three variants with 6 zones at each panel, to be mounted at rack to enable volume of each
zone to be controlled or set at the control room.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Amperes VR7605
Summary of Contents for Amperes VR7605
- Page 1 ZONE 6 Thank you for choosing another quality product from Amperes Electronics. VR series is available in three variants with 6 zones at each panel, to be mounted at rack to enable volume of each zone to be controlled or set at the control room.
- Page 2 Parts Identifications Front View ZONE 1 ZONE 3 ZONE 5 ZONE 6 ZONE 2 ZONE 4 Rear View VOLUME CONTROL 6 zones volume controls with 50 / 100 / 150W 100V line rating for each zone. 2. VOLUME CONTROL MODULE The VC module comprises of mounting bracket and the electronic parts assembled together.
- Page 3 Zone 5 Zone 1 Power Amplifier 100V Zone 5 Zone 6 Technical Specifications VR7605 / VR7610 / VR7615 Power rating 50 / 100 / 150W 100V line / zone Overriding voltage 24V DC Overriding current 15 mA per channel Attenuation 6 steps incl.
- Page 4 Only Amperes Electronics Service Centres are allowed to make warranty repairs : a list of Amperes Electronics Service Centres may be asked for by the purchaser or send directly to Amperes Electronics Sdn Bhd at 70 Jalan Industri PBP 3, Tmn Perindustrian Pusat Bandar Puchong, 47100, Puchong, Selangor, Malaysia or its authorized dealers.
