Teac WS-A70 Quick Start Manual

Connecting with AirPlay Settings

new AirPlay speaker list.
It takes another one minute until the WS-A70
appears in this list, after the main unit shows
volume level "50".
You can change speaker name in this step, for
easy organization. (ex. Living Room Speaker)
leave from the Settings.
Refer to "Start up the App" in the
Network Application Manual.
(Scan the QR code on page 1)
4
Tap "Settings"
on the iOS device.
Tap "Wi-Fi"
in the Settings.
Scroll upwards, and
select "WS-A70" in the
Tap "Next" and
follow the steps.
Connection complete.
Tap "Done" then,
Tap here to change speaker name.
iOS
WS-A70
Network Music System

Before you start

The WS-A70 requires network connection via either Wireless LAN (Wi-Fi) or LAN Cable.
This Quick Start Guide explains how to connect the WS-A70 to the same network to which your smartphone or tablet
is connected, and set the WS-A70 to play music.
Music Playback via Wireless LAN (Wi-Fi)
Confirm that your smartphone or tablet is
connected to your Wi-Fi.
Use AirPlay Settings or Google Home app
to apply network settings to the WS-A70.
Use Google Home
(see page 2 and 3)
Connection completes.
Visit the TEAC web site and see the "Start up the App" section in the
Network Application Manual (PDF).

Quick Start Guide

(Network Setup)
Music Playback via LAN cable
Connect the WS-A70 and Wi-Fi Router
via a LAN cable.
IP Address is automatically assigned
Connection completes.
Use AirPlay*
(see page 4)
* iOS only
1. Scan the QR code. (http://teac-global.com/)
2. Select your country/region in the TEAC Downloads section (lower left).
3. Select the WS-A70.
4. Select the Network Application Manual (PDF).
OPWSA70TEA04
1
