Bullet Camera

User Manual

UD.6L0201D0170A01
www.hikvision.com
Thank you for purchasing our product. If there
are any questions, or requests, please do not
hesitate to contact the dealer.
This manual applies to
Type
Model
DS-2CE1582P(N)-IR
DS-2CE15C2P(N)-IR
DS-2CE1682P(N)-IT3
DS-2CE16C2P(N)-IT3
DS-2CE1682P(N)-IT5
DS-2CE16C2P(N)-IT5
DS-2CE1582P(N)-VFIR3
This manual may contain several technical
incorrect places or printing errors, and the
content is subject to change without notice.
The updates will be added to the new version of
this manual. We will readily improve or update
the products or procedures described in the
manual.
DISCLAIMER STATEMENT
Underwriters Laboratories Inc. ("UL")has not
tested the performance or reliability of the
security or signaling aspects of this product.
0100001030115
UL has only tested for fire, shock or casualty
hazards as outlined in Ul's Standard(s) for Safety,
UL60950-1.
UL Certification does not
cover the
performance or reliability of the
security or
signaling aspects of this product UL MAKES NO
REPRESENTATIONS, WARRANTIES OR
CERTIFICATIONS WHATSOEVER REGARDING
THE PERFORMANCE OR RELIABILITY OF ANY
SECURITY OR SIGNALING RELATED FUNCTIONS
OF THIS PRODUCT.
Regulatory Information
FCC Information
FCC compliance: This equipment has been
tested and found to comply with the limits for a
digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated in
a commercial environment. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed and used
in accordance with the instruction manual, may
cause harmful interference to radio
communications. Operation of this equipment in
a residential area is likely to cause harmful
interference in which case the user will be
required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful
interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation.
EU Conformity Statement
This product and - if applicable -
the supplied accessories too are
marked with "CE" and comply
therefore with the applicable harmonized
European standards listed under the Low Voltage
Directive 2006/95/EC, the EMC Directive 2004/
108/EC.
2002/96/EC (WEEE directive):
Products marked with this symbol
cannot be disposed of as unsorted
municipal waste in the European
Union. For proper recycling, return
this product to your local supplier
upon the purchase of equivalent new equipment,
or dispose of it at designated collection points.
For more information see:
www.recyclethis.info.
2006/66/EC (battery directive):
This product contains a battery
that cannot be disposed of as
unsorted municipal waste in the
European Union.
See the product documentation for specific
battery information. The battery is marked with
this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg).
For proper recycling, return the battery to your
supplier or to a designated collection point. For
more information see:
www.recyclethis.info.
1 Introduction
1.1 Product Features
This series of camera adopts new generation
sensor with high sensitivity and advanced
circuit design technology. It features high
resolution, low image distortion and low noise
features, etc., which makes it suitable for
surveillance system and image processing
system.
●High-performance sensor and high resolution
bring high-quality image
●IR LED enables the day/night surveillance
●IR cut filter auto switch
●ATW brings high color rendition
●Ingress protection:IP66
1.2 Overview
Video Cable
Mounting Base
Power Cable
Sun Shield
Lens
IR LED
Figure 1-1 Overview of Type Ⅰ Camera
Adjustable Screw
Sun Shield
Power Cable
Lens
Video Cable
IR
LED
Figure 1-2 Overview of Type Ⅱ Camera
Adjustable Screw
Sun Shield
Power Cable
Lens
Video Cable
IR LED
Figure 1-3 Overview of Type Ⅲ Camera
Mounting Base
Video Cable
Power Cable
Sun Shield
Lens
IR LED
Figure 1-4 Overview of Type Ⅳ Camera
2 Installation
Before you start:
●Make sure that all the related equipment is
power-off during the installation.
●Check the specification of the products for the
installation environment.
●Check whether the power supply is matched
with your AC outlet to avoid damage.
●If the product does not function properly,
please contact your dealer or the nearest
service center. Do not disassemble the
camera for repair or maintenance by
yourself.
●Please make sure that the ceiling or the wall
is strong enough to withstand 3 times the
weight of the camera.
