Power works 5100313 Owner's Manual page 14

ASSEMBLY
CONNECTING HIGH PRESSURE HOSE TO TRIGGER HANDLE
• Align the pressure hose with the trigger handle and push up and into position.
• With hose pushed into position on the trigger handle, secure in place by turning the hose lock
clockwise until fully tightened.
NOTE: For easier installation of the hose to the unit or trigger it is suggested to add pressure
washer or dish detergent to the rubber seal at each end of the hose. This will allow for easier
LQVWDOODWLRQ DQG D VQXJ ¿W
CONNECTING THE HIGH PRESSURE HOSE TO WATER OUTLET
• Remove the hose connector cap.
• Connect the other end of the hose to the hose connector, secure in place by turning the hose
lock clockwise until fully tightened.
①
Fig. 5
Outlet
Connector
②
High Pressure
Hose
14
See Figure 5.
See Figure 6.
