Power works 5100313 Owner's Manual page 13

ASSEMBLY
ASSEMBLING THE FRONT PANEL AND GUN HOLDER
• Line up the screw sleeves with the holes in the upper handle and push through.
• Insert the screw and turn clockwise with a phillips head screw driver (not included) until the
screw is tight.
ASSEMBLING THE HOSE HOOK
• Line up the hose hook upper end with the holes on the back of the front panel
• Insert the hose hook end into the hole and push through.
• Press the hose hook lower end into the clip on the back of the front panel.
See Figure 4.
hose hook
upper end
hole
lower end
clip
13
See Figure 4.
Fig. 4
