Congratulations! You've just purchased the battery of the future!
Please read these instructions before installing your ODYSSEY .

INSTALLATION:

Your ODYSSEY is normally ready to install right out of the box! Measure the battery
voltage; if it is 12.65 volts or greater, install; if less, then refer to the charging section.
ANY OF THE FOLLOWING WILL VOID YOUR
WARRANTY:
-EXPOSING BATTERY TO GASOLINE OR DIESEL FUEL
-REMOVING THE LABELED COVER
-REMOVING OR DESTROYING THE BATTERY'S DATE CODE
DO NOT SHORT CIRCUIT YOUR ODYSSEY'S TERMINALS! Remove any
metallic items such as watches, bracelets and other personal jewelry to ensure safe
installation.
All
A
Other
M6 x 1
B
THREAD
Models
0.61"
C
A. Bolt
B. Washer
C. Battery
NOTE: PC535 Bolt installation
PC625
is in horizontal orientation.
C
DIN
TERMINAL
A. Brass Post
B. Helicoil Insert
B
C. Accessory Bolt
3/8" Course Thread
A
A
(not included)
D. Battery
SAE
Terminals
D
NTS
1. Using proper procedures as recommended by the manufacturer, carefully
disconnect the cables from your old battery and remove it from the vehicle.
Return the spent battery to the dealer for proper recycling.
2. Inspect existing battery cables for corrosion, acid damage or insulation
deterioration. Replace if deterioration is present.
3. Position your ODYSSEY in the battery holder and fasten firmly to the
vehicle.
4. Connect the positive cable from your ignition to the Positive (+) terminal.
5. Connect the negative cable from your engine or chassis to the Negative (-)
terminal.
6. Torque the bolt, screw or nut per the specification noted in table. If you're
using the Accessory Bolt (C), hold the Brass Post (A) with vise grips and counter
torque. Do the same with GM automotive battery cable installation.
NOTE: This is a valve regulated sealed battery and never needs to have
water or electrolyte (acid) added. Warranty will be void if opened!
®
3/8-16 UNC
THREAD
0.74"
PC2150
3/8"-16 UNC
THREAD
B
A. 18.2 mm/0.716" MAX
B. 24.5 mm/0.964" MAX
PC2250
Keep your receipt. Receipt is required for longest Warranty Protection.
For your
convenience,
this space is
provided for
attaching
your original
receipt.
WARRANTY: FULL 2-YEAR & 3-YEAR REPLACEMENT
ODYSSEY Batteries of EnerSys Energy Products Inc. (seller), warrants its batteries to be
free of defects in material and workmanship.
This warranty is effective for 2 years in
powersports applications and 3 years in automotive/commercial/industrial applications from
the date of purchase with original receipt; 2 and 3 years respectively from manufacturer's
shipping date if no original receipt is available; or within 400 cycles to 80% depth of discharge,
whichever occurs first. Within the warranty period, the battery will be replaced free of charge
if adjustment is necessary due to defect in material or workmanship (not merely discharged).
Simply return the battery to any authorized ODYSSEYdealer with the original receipt for a
replacement. This warranty may vary from country to country; contact your appropriate sales
region for confirmation.
ODYSSEY CONVENTIONAL
GENERAL PROVISIONS
A. Seller has no obligation under the limited warranty set forth above in the event the battery
is damaged or destroyed as a result of:
Willful abuse or neglect or if the top decorative cover has been removed.
Natural forces such as wind, lightning, hail; damage due to fire, collision, explosion, vandalism,
theft, penetration, or opening of the battery case in any manner.
Overcharging, undercharging, charging or installing in reverse polarity, improper maintenance,
allowing the battery to be deeply discharged via a parasitic load or mishandling of the battery
such as but not limited to using the terminals for lifting or carrying the battery.
Failure to properly install the battery or lack of metal jacket for high temperature or vibration
applications.
Normal deterioration in the electrical qualities or the acceleration of such deterioration due to
conditions that accelerate such deterioration.
If the battery is used for any application that requires higher cranking power or a greater reserve
rating than the battery is designed to deliver or the battery capacity is less than the battery
capacity specified by the vehicle manufacturer or the battery is otherwise used in applications
for which it was not designed.
B. To obtain warranty service:
1. Return battery to any authorized ODYSSEY wholesaler or dealer.
2. If the battery is determined to be defective for material or workmanship under terms of the
warranty, it will be replaced.
THIS LIMITED WARRANTY IS IN LIEU OF, AND SELLER DISCLAIMS AND EXCLUDES, ALL
OTHER WARRANTIES, STATUTORY, EXPRESS OR IMPLIED, INCLUDING, WITHOUT
LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE THAT WOULD OTHERWISE BE IN EFFECT FOR LONGER THAN THE
EFFECTIVE WARRANTY PERIOD. SELLER'S EXCLUSIVE LIABILITY FOR BREACH OF
WARRANTY SHALL BE TO REPLACE THE BA TTERY WITHIN THE EFFECTIVE WARRANTY
PERIOD. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY LOSS OR DAMAGES OF ANY
OTHER KIND, WHETHER DIRECT, INCIDENTAL, CONSEQUENTIAL, EXEMPLARY, SPECIAL
OR OTHERWISE NOR SHALL SELLER BE LIABLE FOR ANY REMOVAL OR INSTALLATION
EXPENSE, OR THE LOSS OF TIME OR PROFITS.
Some countries and/or states do not allow limitations on how long an implied warranty lasts or
the exclusion or the limitation of incidental or consequential damages, so the above limitations
may not apply to you. This warranty gives you specific legal rights which may vary from country
to country and/or state to state.
