OWNER'S MANUAL
Engineered to take you to the red line – and the finish line
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the extreme racing and is the answer not in the manual?

Questions and answers

Related Manuals for Odyssey extreme racing

Summary of Contents for Odyssey extreme racing

  • Page 1 OWNER’S MANUAL Engineered to take you to the red line – and the finish line ®...
  • Page 2 SUPERIoR CRANkING AND FAST CHARGE CAPABILITY The 5 second cranking power of ODYSSEY Extreme Racing batteries is double to triple that of equally sized conventional batteries, even when the temperature is as low as - 40°C (-40°F). Also, with simple constant voltage charging (alternator or independent charger), there is no limitation on the inrush current, so the user is assured of fast charge recovery.
  • Page 3 2. Inspect existing battery cables for corrosion, acid damage or insulation deterioration. Replace if deterioration is present. 3. Position your ODYSSEY Extreme Racing battery in the battery holder and fasten firmly to the vehicle. 4. Connect the positive cable from your ignition to the Positive (+) terminal.
  • Page 4 7 . 1 5 3 . 0 0 6 . 6 5 ( 1 8 1 . 5 ) ( 7 6 . 3 ) ( 1 6 7 . 8 )
  • Page 5 6 or more hours, Figure 2 can be used to determine the SOC of the ODYSSEY open circuit storage time in weeks Extreme Racing battery. Use a high quality digital voltmeter to measure its OCV. The graph shows Figure 3: ODYSSEY Extreme Racing™...
  • Page 6 12.18 Volts 11.88 Volts To get long life from the ODYSSEY Extreme Racing battery, it is important that the battery is kept near full charge, approximately 12.8 volts. If there are electrical loads during storage, then the negative battery cable should be disconnected or an independent float charger used. Low power 2.0 amp chargers that reach final charging voltages of 13.5V to 13.8V for storage charge will keep a fully charged battery fully...
  • Page 7 Disconnect the negative battery cable to prevent any applied electrical load during storage. The ODYSSEY Extreme Racing battery cannot freeze down to -40°C (-40°F), so it can be left in the vehicle. It can be stored for 2 years or more below 77°F.
  • Page 8 • W A R N I N G - D o N O T u s e a n y t y p e o f o i l , o r g a n i c s o l v e n t , a l c o h o l , d e t e r g e n t , s t r o n g a c i d s , s t r o n g a l k a l i s , p e t r o l e u m- b a s e d s o l v e n t o r a mmo n i a s o l u t i o n t o c l e a n t h e j a r s o r c o v e r s .
