Radio Shack Surveyor Drone User Manual

Surveyor Drone
Back LEDs (green)
Install Batteries in the Transmitter
1. On the transmitter, set the ON/OFF switch to OFF.
2. Use a screwdriver to open the battery compartment.
3. Insert two AAA batteries (not included), matching
the polarities marked inside. Use alkaline batteries
for optimal performance.
During play, if the transmitter's
LED flashes, replace the
batteries.
©2014 RadioShack Corporation.
All rights reserved. RadioShack is a registered trademark used by RadioShack Corporation.
6001145_UG_EN_072914.indd 1
Rotor Blades (4)
Front LEDs (white)
Camera Lens
Charge the Drone Battery
Your drone uses a lithium polymer battery for power.
1. Hold the battery connector (NOT the cable) and carefully unplug
the battery from the drone.
2. Use the USB charging cable to connect the battery to a USB power
source, such as a laptop. The LED on the USB connector lights red
during charging, and turns off when charging is complete.
A full charge takes about 35 minutes. When the battery is fully
charged, the drone can fly up to 5 minutes.
3. After charging, unplug the USB charging cable. Do not attempt to
overcharge the battery.
Caution:
• Use only the supplied lithium battery. Using any
other battery may damage the drone.
• Only use the included USB charging cable to
charge the drone battery.
LED
Age 14+
Get Ready to Fly
1. Open the drone battery compartment door and find the battery socket.
2. Plug the drone battery to the socket. The four LEDs (two in white in the
front, two in green in the back) flash.
3. Insert the battery with its cable into the battery compartment.
4. Secure the compartment door.
5. Place the drone on level ground.
6. Switch on the transmitter. The transmitter's LED lights.
7. Move the throttle all the way from the descend position to ascend
and back to descend to pair the transmitter with the drone. The
drone's blades remain still during pairing. When paired, the drone's
LEDs stop flashing and remain on.
Note: If pairing fails, switch off the drone and transmitter and repeat the
steps above, or move locations to avoid interference.
Fly Your Drone
1. After pairing, press the steering control to switch between high speed (double beep) and normal
speed (single beep).
2. For beginners: With the drone on the ground, move the throttle forward to fly.
For advanced users: Hold the transmitter with one hand, resting your thumb on the throttle.
Then throw the drone about three meters away from you, and promptly move the throttle
forward to fly. The drone adjusts itself automatically and flies stably.
3. To land your drone, slowly move the throttle backward to descend. Avoid moving the throttle too
quickly, as that can stop the blades instantly and cause the drone to crash.
4. When you finish playing, disconnect and remove the drone battery and turn off the transmitter.
Throttle
• Speed up (ascend)/
slow down (descend)
• Turn right/left
• Play flip stunts
We hope you enjoy your Surveyor Drone from
RadioShack. Please read this user's guide before
setting up and using your drone.
What's Included
• Surveyor Drone • Transmitter
• USB Charging Cable • Spare Blades (4)
• 3.7V Drone Battery • User's Guide
1
2
ON/OFF
LED
Steering
• Move forward/
backward
• Slide right/left
• Switch between
high and low speed
07A14
