RTS Breakout Panel XCP-48-RJ45 Technical Manual page 3

XCP-48-RJ45
FIGURE 1.
The XCP-48-RJ45 is the newly created 48-port RJ-45
breakout panel with MDR connector for the AIO-16 and
Cronus. It allow you to expand the number of RJ-45 ports on
the Intercom system.
NOTE: When using the 48-port RJ-45 breakout panel,
you MUST use the MDR backcard for both the
AIO-16 and Cronus.
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Ports Ports
1-8 9-16
1 2 3 4 1 2 3
XCP-48-RJ45
5 6 7 8 5 6 7
J1 J2
RJ-45
N/A
Keypanel Data -
Audio Out +
Audio In +
Audio In -
Audio Out -
Keypanel Data +
N/A
Ports Ports
17-24 25-32
4 1 2 3 4 1 2 3 4 1
8 5 6 7 8 5 6 7 8 5
J4
J3 J5
Pin Number
8
33
24
49
25
50
7
32
22
47
23
48
CHAPTER 1
XCP-48-RJ45
9000-7809-000
Ports Ports
33-40 41-48
2 3 4 1 2 3 4
6 7 8 5 6 7 8
TELEX COMMUNICATIONS, INC.
MADE IN U.S.A.
J6
MDR Connector
Port Function
1 Data +
1 Data -
1 Audio To Matrix +
1 Audio To Matrix -
1 Audio From Matrix +
1 Audio From Matrix -
2 Data +
2 Data -
2 Audio To Matrix +
2 Audio To Matrix -
2 Audio From Matrix +
2 Audio From Matrix -
3
