IDS805 Alarm Panel Quick Start Guide
THANK YOU FOR CHOOSING IDS TO PROTECT YOU
Congratulations on your purchase of an IDS805 alarm panel. IDS
alarm panels are powerful, versatile and highly configurable
security systems, which should be installed by a professionally
trained installer.
This Quick Start Guide covers basic user functionality to get you
familiar and using the system as quickly as possible. The majority of
panel features are programmable only by an IDS-accredited
installer in possession of the INSTALLER CODE, and are identified
with this symbol@.
Advanced User Functions, are covered in the Advanced User
Manual, available at www.idsprotect.com.
UNDERSTANDING ALARM PANEL FUNCTIONS
When powered up, the panel is either ARMED or DISARMED.
If DISARMED, it is READY or NOT READY.
Entering data confirm by Pressing [*]
[#] to exit programming / menu or to clear data
Successful data entry – single extendedkeypad beep
Failed entry – triple keypad beep
EMERGENCY ALARMS
Emergency alarms can be triggered:
-
on the keypad by holding down [F] for fire, [P] for panic, or
[M] for medical keys
-
Via Fixed Panic Buttons installed by the alarm installer, or
-
Via an IDS remote transmitter, holding down any button for 3
seconds or a dedicated button. (Please confirm with installer)
ARMINGand DISARMING YOUR ALARM
The IDS805 panel provides multiple arming methods and modes to
suit your lifestyle.
AWAY ARM
Use AWAY ARM when you are leaving the premises and want all
entry / exit zones to function as such.
To away arm:
1.
Enter USER CODE or hold down [1] until keypad beeps
2.
Exit premises before exit delay beep sequence completes
STAY ARM
Use STAY ARM when you are in the premises and want some zones
armed and others not
1. Select your stay profile, if there are more than one and the last
profile selected is not the profile you want to stay arm in.
Press [MODE] then [9] [PROFILE NUMBER] [*]
2. Hold the [5] key until the beep.
STAY & GO ARM
Use STAY AND GO when some people are leaving the premises,
others are remaining at home. Will arm in the last stay profile
selected if not changed.
1.
Hold [6] until BEEP
2.
Exit premises before exit delay beep sequence completes
DISARM
1. Enter through nominated entry zones
2. Enter USER CODE before count down is complete
REMOTE ARM / DISARM
Use your remote transmitter to arm / disarm by pressing the
programmed button
WORKING WITH ZONES
BYPASS A ZONE
Bypass a zone to prevent it triggering an alarm when armed
1. Confirm panel is DISARMED
2. Press [*][ZONE NO], [*][ZONE NO]...[#]
CHIME ZONES
The keypad will chime when a CHIME ZONE is violated while the
panel is DISARMED
1.
Hold [2] until BEEP, [ZONE NO] [*]....[#]
VIEWING PANEL INFORMATION
VIEW ALARM MEMORY
View zones that were violated, bypassed or tampered during the
last arm cycle
1.
If ARM LED is flashing before disarming, there are events in
ALARM MEMORY
2.
Confirm panel is DISARMED
3.
Hold [0] till beep
4.
Press [1] [*] to view bypassed zones
5.
Press [2] [*] to view tampered zones
Note: ALARM MEMORY is cleared with next ARM cycle
IDS 805 Quick User Manual 700-266-07A Issued January 2015
WORKING WITH STAY PROFILES
STAY PROFILES enable a user to ARM while bypassing programmed
zones. This is useful when users are in the premises, but want
some zones armed.
CREATE STAY ZONES
STAY ZONES are automatically bypassed when a panel is STAY
ARMED. STAY ZONES are allocated to one of two STAY PROFILES.
1.
Select the desired STAY PROFILE. Press [MODE] then [9]
[PROFILE NUMBER] [*]
2.
Allocate STAY ZONE. Hold [3] until BEEP, ZONE NO... [#]
CREATE BUZZ ZONES
BUZZ zones give USERS warning of a zone being violation before
reporting an ALARM to the control room. The keypad will BEEP for
30 seconds if a BUZZ zone is violated while the panel is STAY
ARMED. If a valid USER CODE is not entered in this period, an alarm
status will be reported to the control room.
1.
Hold [4] until BEEP, ZONE NO [*]...[#]
Note: A zone cannot be a buzz zone and a stay zone
CODES
OVERVIEW OF CODES
The IDS805 Panel supports multiple types of CODES, allowing for
flexibility in use:
There are four different types of USER CODES:
MASTER CODE, code 1, enables its owner to program certain user
functions
USER CODES, codes 2 to 13, allow users to ARM / DISARM and
carry out other basic functionality on the system
Maid's CODE, code 14, allows the system to be disarmed by this
code if the system was armed with the maid's code
Duress CODE, code 15, sends a duress signal to the monitoring
company if used to arm or disarm the system
ADD or CHANGE USER CODE
1.
Hold [*] till BEEP, then [MASTER CODE] [*] [USER No.] [*]
[NEW CODE] [*],[USER No.] [*] [NEW CODE] [*]... continue
until all codes are entered then [#] to exit
Note: User No. 1 = Master Code, No. 14 = Maid's Code and No. 15
= Duress Code
