QUIcK
InStallatIon
GUIde
Grandstream 3005 or 3006
Basic Installation Instructions:
for connecting the GXV-3005 or 3006
video phone to the Internet via a router
connected to a cable or DSL modem
Your Start-up Kit should include:
GXV-3005 or 3006 Main Case
Handset
Phone Cord
Universal Power Adapter
Ethernet Cable
Two Wall Mount Sustaining Brackets
Quick Installation Guide
Installation Guide: Setting Up Your Grandstream GXV 3005/3006
1
Step 1:
Connect the handset to the phone with the provided phone cord.
Step 2:
Connect the WAN port
Step 3:
Connect the power adapter to the 12V DC input on the back of the phone.
Step 4:
Connect a switch or computer to the PC port (optional).
http://www.grandstream.com/user_manuals/
For a complete users guide:
Video Phone
PC Port
5
(optional)
Computer
3
to a switch, router or modem using the Ethernet cable.
5
Headset
Jack
Network
FXO
Power
Video/Audio Ports
or
Port
Jack
3
FXS
4
Port
Note: The 3005 has an FXO port and 3006 has an FXS port
