Heat&Glo KENWOOD SERIES Installation Instructions

Leave this manual with party responsible for
use and operation.
CAUTION
Sharp Edges
• Wear protective gloves and safety
glasses during installation.
CAUTION
• These instructions apply only to the cabinet and facing
material that will surround the fi rebox.
• See the fi replace manufacturer's installation instructions to
ensure that all clearance and installation requirements are
being met.
WARNING
Risk of Fire
• Improper installation or adjustment can
cause injury or property damage.
assistance or additional information, contact
a qualifi ed installer, service agency or the
gas supplier.
• Comply with all minimum clearances to
combustibles as specifi ed in the fi replace
manual.
Figure 1. Kenwood Corner Mantel Shown with Optional Base (Left) or without Base (Right).
KENWOOD CORNER SURROUND
- Installation Instructions -
For
Heat & Glo • Kenwood Corner Surround • 2118-934 • 4/07
CAUTION
It is recommended that two people assemble this mantel due to
its weight and upright positioning.
PREPARATION
Before beginning installation of this mantel, verify that the walls
and fl oor in the area of the installation are clean, plumb and
level. Any major deviation should be remedied before installing
the fi replace, marble or the mantel /cabinet.
These questions should also be considered and answered
before beginning installation of the mantel.
a. Is base molding already installed?
b. Where are the electrical outlets or fi rebox switch?
c. Is there enough distance between windows and edge
of cabinet?
d. Is the fi replace centered between walls?
e. Where is the return air vent located?
f. Is the fi replace centered between windows?
g. Where are the electrical & cable outlets positioned?
h. What type of fi nished fl ooring is to be installed?
Tools and supplies needed:
#2 Phillips Screwdriver
High Temperature Silicone Caulk
Finishing Nails & Hammer
Level
1
